The SIEMENS 1FK7061-4CH71-1BA2 SIMOTICS S-1FK7-HD is a high-efficiency synchronous motor engineered for demanding industrial applications. With a nominal power of 2 kW and operating voltage of 600 V, this motor delivers a rated torque of 6.4 Nm at 4500 rpm. The naturally cooled design ensures effective heat dissipation directly through the motor surface, eliminating the need for external cooling while maintaining high overload capability. Its IP65 protection rating guarantees reliable performance in harsh industrial environments, while the flange IP67 ensures safe mounting and operational integrity in varied applications.

Equipped with a rotatable absolute encoder singleturn 24-bit with DRIVE-CLiQ interface (ENCODER AS24DQI), this motor provides precise speed and position control. The shaft includes a fitted key with tolerance N, facilitating easy integration into existing systems. The 1FK7-HD series supports seamless combination with SINAMICS S120/S220 drive systems, enabling highly functional drive configurations tailored to specific industrial needs.

Overview

SIMOTICS S-1FK7 motors are compact, permanent-magnet synchronous motors designed for maximum adaptability and performance. Available in a wide range of options, including gearboxes and encoders, they can be configured for virtually any modern machine requirement. These motors are ideal for high-speed and dynamic applications, offering minimal commissioning overhead and allowing for efficient compensation of disturbances. Their high overload capability and robust design ensure consistent performance even under challenging operating conditions.

• Space-saving installation with high power density
• Universal compatibility with industrial drive systems
• Available in high-dynamic and high-inertia variants for specialized applications
• Minimal optimization required for precise closed-loop control
• Supports integration with SINAMICS S120/S220 systems for extended functionality

Applications

• Machine tools
• Robotics and handling systems
• Wood, glass, ceramics, and stone processing
• Packaging, plastics, and textile machines
• Printing machines
• Auxiliary axes

Download

Data Sheet (PDF)

Product Code: 1FK7061-4CH71-1BA2 —
View Siemens Product Page
