1FK7061-4CH71-1QB0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7061-4CH71-1QB0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7061-4CH71-1QB0 SIMOTICS S motor is a highly refined synchronous unit designed to support precise and stable performance within advanced automation environments. As part of the SIMOTICS S-1FK7 High Dynamic range, this motor incorporates a permanent-magnet configuration that increases efficiency and improves responsiveness under variable operating conditions. With a nominal torque of 6.4 Nm and a rated speed of 4500 rpm, it provides dependable motion that aligns with applications requiring fast acceleration and consistent speed control. Its naturally cooled structure enables heat dissipation through the motor surface, supporting continuous reliability even during extended operation.

This model is equipped with a 20-bit absolute single-turn encoder featuring the DRIVE-CLiQ interface for high-resolution feedback. The shaft includes a fitted key manufactured to tolerance class N, allowing secure mechanical integration. A built-in holding brake enhances safety and supports stable positioning in motion control systems. The motor’s IMB 5 construction and flange type 1 contribute to flexible installation in a wide variety of industrial machine designs. With ingress protection rating IP64, the unit withstands challenging environments while maintaining long-term durability.

Overview

SIMOTICS S-1FK7 motors combine compact dimensions with versatile configuration options. Their adaptable structure, encoder selection, and compatibility with gearboxes allow these motors to be tailored to numerous industrial requirements. By integrating with SINAMICS S120 or S220 drive systems, they form a powerful and coordinated platform for precision-driven applications.

The series supports closed-loop operation, optimized thermal behavior, and impressive overload characteristics. These attributes ensure stable performance while reducing downtime and maintenance demands. The broad range of variants also makes the product family suitable for modern machine architectures requiring flexibility and reliable motion control.

Design & Key Features

• Permanent-magnet synchronous motor engineered for dynamic performance
• Absolute single-turn 20-bit encoder with DRIVE-CLiQ interface (AS20DQI)
• High efficiency and responsive acceleration behavior
• Shaft with fitted key, tolerance class N
• Holding brake included for secure static operation
• IP64 protection for demanding industrial conditions
• IMB 5 construction with flange type 1

Download

Data Sheet (PDF)

Product Code: 1FK7061-4CH71-1QB0
