1FK7062-2AC71-1BB2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7062-2AC71-1BB2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7062-2AC71-1BB2 SIMOTICS S motor is a versatile synchronous motor built for precision and reliability in industrial automation. Rated at 1.5 kW with a nominal torque of 8.5 Nm and a speed of 2000 rpm, it delivers stable and efficient performance across a variety of applications. Its naturally cooled design ensures consistent operation without the need for external cooling, while the robust IMB 5 frame and flange type 1 enable straightforward mounting in compact spaces. The motor is equipped with a rotatable power connector for flexible installation and ease of wiring.

This motor integrates a high-precision 24-bit single-turn absolute encoder with the DRIVE-CLiQ interface (AS24DQI), offering accurate speed and position feedback. The shaft features a feather key with tolerance class N and includes a holding brake, ensuring precise positioning and enhanced safety during operation. The IP65 degree of protection on the drive end and IP67 on the flange make it resilient against dust and water ingress, allowing for reliable performance even in challenging industrial environments.

Overview

SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors designed to adapt seamlessly to modern machine requirements. The extensive product range, available gearboxes, and integrated encoders allow for tailored solutions to meet specific operational demands. These motors can be paired with SIEMENS SINAMICS S120 or S220 drives, creating a high-function system for precise motion control and dynamic performance.

Engineered for applications without external cooling, these motors dissipate heat effectively through the motor surface while maintaining high overload capability. Their flexible configuration and high power density make them ideal for machine tools, robotic systems, packaging machinery, and various motion-critical processes.

Design & Key Features

• High-precision permanent-magnet synchronous motor for industrial automation
• Power rating: 1.5 kW, Torque: 8.5 Nm, Speed: 2000 rpm
• Single-turn absolute encoder 24-bit with DRIVE-CLiQ interface (AS24DQI)
• Feather key shaft with tolerance N and holding brake
• Rotatable power connector for flexible wiring
• Frame type IMB 5, flange 1 for compact mounting
• Ingress protection IP65 DE / IP67 flange
• Compatible with SINAMICS S120/S220 drives for integrated motion control

Download

Data Sheet (PDF)

Product Code: 1FK7062-2AC71-1BB2
