1FK7062-2AC71-1PA2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$1,490.20
A high-precision SIEMENS SIMOTICS S 1FK7062-2AC71-1PA2 synchronous motor built for stable, efficient motion performance with resolver feedback and durable construction.
1FK7062-2AC71-1PA2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS 1FK7062-2AC71-1PA2 is a precision-engineered synchronous motor developed for applications where stable motion, dependable torque characteristics, and smooth performance are essential. Belonging to the SIMOTICS S-1FK7 family, this motor is designed to support a wide range of industrial motion tasks by combining robust mechanical construction with advanced feedback technology. It offers a nominal torque of 8.5 Nm, a rated speed of 2000 rpm, and a 1.5 kW power class, making it suitable for machines that rely on steady, accurate rotational output. Its natural cooling concept helps maintain predictable thermal performance without external cooling components, while the IMB 5 mounting configuration simplifies integration into existing mechanical layouts.
This model features a rotatable power connector and a 2-pole resolver equipped with a DRIVE-CLiQ interface, enabling reliable communication and precise tracking of speed and position. The shaft includes a feather key with tolerance class N to enhance mechanical stability in demanding continuous-duty environments. Protection ratings of IP65 on the motor body and IP67 on the drive end flange ensure resistance to dust and moisture, supporting long-term reliability even in challenging production environments.
Overview
SIMOTICS S-1FK7 motors are compact synchronous units built with permanent-magnet technology to deliver strong power density and installation flexibility. Their wide variety of encoder systems, gear options, and mechanical variants makes them adaptable to numerous equipment platforms. When paired with SINAMICS S120 or S220 drive systems, these motors form a high-performance solution that supports coordinated motion, precise closed-loop control, and smooth operation.
The family is engineered for elevated overload capacity and thermal efficiency, with heat transferred naturally through the motor housing. This allows the motors to maintain stable output across extended duty cycles. Their compact form factor makes them suitable for machine tools, robotic systems, packaging equipment, automated material handling, and specialized industrial machinery.
Design & Key Features
- Robust synchronous motor with permanent-magnet design
- 8.5 Nm nominal torque and 2000 rpm rated speed
- 2-pole resolver with DRIVE-CLiQ interface for accurate feedback
- Feather-key shaft, tolerance class N
- Rotatable power connector for flexible installation
- Protection class IP65/IP67 for demanding industrial environments
- Natural cooling and IMB 5 mounting configuration
Download
Product Code: 1FK7062-2AC71-1PA2
More Siemens products at Turll.com
| Weight | 9.201 kg |
|---|
