1FK7062-2AC71-1RB0 SIEMENS Exclusive Synchronous Motor Original Brand New

1FK7062-2AC71-1RB0 SIEMENS Exclusive Synchronous Motor Original Brand New

The SIEMENS 1FK7062-2AC71-1RB0 Exclusive Synchronous Motor delivers precision performance and exceptional reliability for demanding industrial applications. As part of the SIMOTICS S-1FK7 series, this permanent-magnet synchronous motor is designed for compact installation while offering high power density. Its naturally cooled design ensures efficient heat dissipation directly through the motor surface, eliminating the need for external cooling systems. With integrated DRIVE-CLiQ absolute encoders, including a 20-bit single-turn and 12-bit multi-turn AM20DQI, this motor provides precise position and speed feedback for advanced motion control systems.

Equipped with 1.5 kW rated power, 600 V DC link voltage, 8.5 Nm torque at 100K, and 2000 rpm nominal speed, the motor features a rotatable power connector and a feather-key shaft with tolerance N. The built-in holding brake increases operational safety, while the IP64 degree of protection guarantees reliable performance in environments exposed to dust and moisture. These specifications make it suitable for a wide range of applications, from machine tools and robotic handling systems to packaging, printing, and processing machines in wood, glass, ceramics, plastics, and textiles.

Overview

SIMOTICS S-1FK7 motors combine compact mechanical design with high operational flexibility. The extensive product range allows for customization through various encoder options, mechanical variations, and gearboxes, adapting the motors precisely to each application. When paired with SINAMICS S120 or S220 drive systems, these motors form a high-performance solution, offering superior functionality and reliable closed-loop control. Their high overload capability ensures stable performance even under fluctuating loads or rapid acceleration demands.

Design & Key Features

• Extremely compact and space-saving design with high power density.
• Integrated absolute encoders for precise speed and position monitoring.
• Rotatable power connector for flexible installation.
• Feather-key shaft with holding brake for secure operation.
• High dynamic and high-inertia variants available for tailored motion performance.
• Reduced commissioning and optimization effort due to advanced closed-loop characteristics.

Download

Data Sheet (PDF)

Product Code:1FK7062-2AC71-1RB0
