Siemens Contactor AC-3, 9A/4kW, 400V, W/O, AC 110V, 50/60Hz, size S00, screw terminal
Siemens Contactor AC-3, 9A/4kW, 400V, W/O, AC 110V, 50/60Hz, size S00, screw terminal
Siemens 3MT8009‑1AF00 G1A is a compact yet durable AC‑3 contactor from the SIRIUS Size S00 series, engineered for light-duty three-phase motor control. It features a three-pole design with screw-type terminals optimized for tight panel installations. Rated for 9 A at 400 V, it supports motors up to 4 kW, making it suitable for small compressors, fans, and conveyor drives. The coil operates at 110 V AC (50/60 Hz), as denoted by the "AF00" suffix, and the device includes 1 normally open (NO) + 1 normally closed (NC) auxiliary contact, offering flexibility for control logic, interlocking, and signal feedback
Visit 3MT8009-1AF00 G1A
For more our products visit turll.com
| SKU / Model | 3MT8009-1AF00 G1A |
|---|---|
| Weight | 0.206 kg |
| Dimensions | 50 × 61.5 × 77.5 mm |
