6AG1241-1CH30-5XB1 Siemens SIPLUS S7-1200 CB 1241 RS485 Original Brand New
$345.90
6AG1241-1CH30-5XB1
Siemens SIPLUS S7-1200 CB 1241, based on 6ES7241-1CH30-1XB0 with conformal coating, -40…+60 °C, start up -25 °C, RS-485, terminal block, supports Freeport
[ez-toc]
Overview
- For fast, high-performance serial data exchange via point-to-point connection
- Implemented protocols: ASCII, USS drive protocol, Modbus RTU
- Additional protocols can be loaded later
- Simple parameterization with STEP 7 Basic
- Can be plugged directly into the CPU
Note:
SIPLUS extreme products are based on SIMATIC standard products. The contents listed here were taken from the respective standard products. SIPLUS extreme-specific information was added.
Application
The CB 1241 communication board RS 485 is used for fast, high-performance serial data exchange via point-to-point connections.
Point-to-point coupling is possible, for example, to:
- SIMATIC S7 automation systems and systems of many other manufacturers
- Printers
- Robot controls
- Modems
- Scanners
- Bar code readers, etc.
The CB 1241 communication board RS 485 can be plugged directly into all SIMATIC S7-1200 CPUs.
This provides users with the following advantages:
- Optimal adaptation:
With communication boards, users can optimally adapt their controllers even to more complex tasks. - Flexibility:
If the task is expanded subsequently, the controller can be upgraded. Updating of the user program is extremely simple. - Use where space is limited:
The communication boards are directly plugged into the CPU, enabling the controller to be expanded without taking up any additional space.
Design
The communication boards are plugged straight into the holder on the front of the S7-1200 CPU.
- Installation:
Communication boards are plugged directly into the SIMATIC S7-1200 CPU and are thus connected electrically and mechanically with the CPU. - The installation dimensions of the CPU remain unchanged.
- Replacement of all communication boards is facilitated by removable terminals (“permanent wiring”).
Function
On the Communication Board CB 1241 RS 485, the following standard protocols are available:
- ASCII:
For interfacing to third-party systems with simple transmission protocols, e.g. protocols with start and end characters or with block check characters. The interface handshake signals can be queried and controlled via the user program. - Modbus:
For communication according to the Modbus protocol with RTU format:- Modbus Master:
Master-slave interfacing with SIMATIC S7 as master. - Modbus slave:
Master-slave interfacing with SIMATIC S7 as slave; message frame traffic from slave to slave not possible.
- Modbus Master:
- USS drive protocol:
Instructions for connection of USS protocol drives are specifically supported. In this case, drives exchange data over RS485. It is then possible to control these drives, and to read and write parameters.
Additional drivers can also be downloaded.
Parameterization
The parameterization of the Communication Board CB 1241 is particularly user-friendly and simple with STEP 7 Basic:
The user specifies the properties of the module by means of a parameterization environment integrated into STEP 7 Basic.
6AG1241-1CH30-5XB1
Siemens SIPLUS S7-1200 CB 1241, based on 6ES7241-1CH30-1XB0 with conformal coating, -40…+60 °C, start up -25 °C, RS-485, terminal block, supports Freeport
Visit 6AG1241-1CH30-5XB1
For more our products visit turll.com
| Weight | 0.033 kg |
|---|---|
| Dimensions | 50 × 82 × 28 mm |
