6AG1521-1FH00-7AA0 Siemens SIPLUS S7-1500 DI 16x230V AC BA Original Brand New
$958.00
6AG1521-1FH00-7AA0
Siemens SIPLUS S7-1500 DI 16x230V AC BA based on 6ES7521-1FH00-0AA0 with conformal coating, -40…+70 °C, digital input module, 16 channels in groups of 4; input delay 20 ms; input type 1 (IEC 61131)
[ez-toc]
Overview
- 16 and 32-channel digital input modules
- For flexible adaptation of the controller to the corresponding task
- For subsequent expansion of the system with additional inputs
Note:
SIPLUS extreme products are based on SIMATIC standard products. The contents listed here were taken from the respective standard products. SIPLUS extreme-specific information was added.
Application
Digital input modules record 24 V DC or 230 V AC signals in the plant and forward them to the control. Switches and 2, 3 or 4-wire proximity switches can be connected.
The input modules have settable parameters and diagnostic functions and can thus be adapted flexibly to the respective process requirements.
Design
- Installation on the S7-1500 mounting rail using one single screw
- Standardized 40-pin front connector using screw terminal or push-in technology
- Standardized, harmonized front connector assignment for easier wiring
- Connectable core cross-sections: 0.25 mm2 to 1.5 mm2 (AWG24 to 16)
- Integrated potential bridges for flexible creation of potential groups
- Front connector can be set to prewiring position
- Front flap with expandable cable compartment, even if fully wired
- Unambiguous labeling on front of module:
- Module type
- Article No.
- Hardware and firmware version
- Channel numbers labeling
- Cabling diagram
Included in the scope of delivery:
- One labeling strip for manual labeling
- One U connector
- Printed front door
Function
- Uniform display and diagnostics concept:
- Module status display for ERROR (red LED) and RUN (green LED)
- Channel status display for signal state log. “0” and log. “1” (green LED) or indication of wire break (red LED)
- 1:1 assignment of the channel status display (LED) to the terminal (except with the 64-channel modules)
- Display for monitoring the 24 V DC supply voltage (green LED)
- Supported functions:
- Identification and maintenance data IM0 to IM3
- Firmware update
- Module-granular shared device and MSI (modular shared input);
in combination with PROFINET these allow assignment to several IO controllers - Channel-specific parameter assignment (only HF modules)
- Hardware interrupts (only HF modules)
- Channel-granular diagnostics (only HF modules)
- Isochronous mode (dependent on the module)
- Integrated counter function (dependent on the module)
6AG1521-1FH00-7AA0
Siemens SIPLUS S7-1500 DI 16x230V AC BA based on 6ES7521-1FH00-0AA0 with conformal coating, -40…+70 °C, digital input module, 16 channels in groups of 4; input delay 20 ms; input type 1 (IEC 61131)
Visit 6AG1521-1FH00-7AA0
For more our products visit turll.com
| Weight | 0.346 kg |
|---|---|
| Dimensions | 150 × 150 × 45 mm |
