6AV7860-1EX21-5AB1 Siemens SIMATIC Flat Panel Monitor V2 Cable Set Original Brand New
$463.25
6AV7860-1EX21-5AB1
Siemens SIMATIC Flat Panel Monitor V2 accessories, cable set 15 m, consisting of: CAT6 cable, host module V2 (HDBaseT)
[ez-toc]
Overview
SIMATIC WinCC Unified Runtime
A simple and consistently scalable PC-based visualization system for all applications, from single-user solutions directly on the machine through to complex SCADA solutions.
The basic package includes visualization, communication, alarms/messages, report creation, system structuring, and user administration.
Furthermore, a client for local operation, an additional WinCC Unified Client Operate for remote operator control and monitoring, and a WinCC Unified Client Monitor for monitoring only are also included in the basic package. Additional clients can be enabled with a license.
SIMATIC WinCC Unified is based on native web technologies such as HTML5, SVG and JavaScript. The visualization can be accessed via any modern web browser – without the need for additional installation.
Open interfaces and option packages allow the expansion and implementation of industry-specific application cases. Once created, components can be used comprehensively on all platforms, whether Panel or PC.
Benefits
Functions for all visualization tasks:
- Operator functions
- Graphics and trend displays
- Alarm logging
- Archiving (optional)
- Management of parameter sets (optional)
- Audit (optional)
- Report creation
- Automated report creation (optional)
- User administration
- Flexible runtime
Functionality with Java scripts:
- Consistently scalable expandable from single-user station to distributed systems
- Process visualization using any modern HTML5-capable web browser
Part of the Totally Integrated Automation Portal:
- Support of the SIMATIC S7-1200/1500 and the SIMATIC S7-300/400 Controllers
- Access to tags with symbolic and absolute addressing
- Full text alarms of the SIMATIC S7-1500 Controller
- Support of OPC UA DA (Client and Server), OPC UA A&C (Client and Server)
Open standards for easy integration:
- Efficient real-time database (option)
- Application Program Interface (API)
- OpenPipe interface
- Integration of your own HTML5 controls in the user interface of WinCC Unified
Design
SIMATIC WinCC Unified PC is available as a software package with 150, 500, 1 000, 2 500, 5 000, 10 000, 50 000 or 100 000 PowerTags.
Additionally, a license for the maximum number of PowerTags within the system limit is also available. Data points with an external connection are designated as PowerTags.
At the same time, internal tags which are exempt from the PowerTag license are provided at no charge.
The basic system can be extended as required with option packages.
Requirements
SIMATIC WinCC Unified Runtime Station:
The performance is determined primarily by the hardware equipment. A powerful processor and more work memory should be selected for larger projects and visualization tasks, in particular. Depending on the options used, e.g. logging, additional free hard disk memory is required.
6AV7860-1EX21-5AB1
Siemens SIMATIC Flat Panel Monitor V2 accessories, cable set 15 m, consisting of: CAT6 cable, host module V2 (HDBaseT)
Visit 6AV7860-1EX21-5AB1
For more our products visit turll.com
| Weight | 3.230 kg |
|---|---|
| Dimensions | 1 × 1 × 1 mm |
