6AV7863-4MA10-2NA0 Siemens SIMATIC IFP2200 V2 Extended Original Brand New
$2,879.33
6AV7863-4MA10-2NA0
Siemens SIMATIC IFP2200 V2 Extended, 22″ multi-touch display (16:9) with 1920×1080 pixel resolution, built-in unit, for 24 V DC, DisplayPort, can be placed up to 100 m away HDBaseT, USB on the rear side, neutral design
[ez-toc]
6AV7863-4MA10-2NA0
Siemens SIMATIC IFP2200 V2 Extended, 22″ multi-touch display (16:9) with 1920×1080 pixel resolution, built-in unit, for 24 V DC, DisplayPort, can be placed up to 100 m away HDBaseT, USB on the rear side, neutral design
Overview
Industrial Flat Panels are LCD monitors in robust industrial design with widescreen format and featuring multitouch operation.
They are ideal for installation in machines, control cabinets, consoles and platforms, or in racks.
The Flat Panels are secured on the rear with special mounting clips included in the scope of supply.
The extended versions can be moved to a distance of up to 100 m from the IPC using a transceiver unit.
Benefits
- Low space requirement and low weight
- Long service life due to rugged industrial design
- Lower energy requirement
- Working free from fatigue
- Well structured operator control and monitoring thanks to various display sizes
Design
- Robust aluminum front, multi-touch display with anti-glare and hardened mineral glass screen
- TFT display in sizes 15″, 19″, 22″ and 24″, each featuring 1920 × 1080 pixels, 16 million colors
Interfaces:
- 1 × Ext-Link for transceiver unit (HDBaseT)
- 2 × USB 2.0 type A (rear)
- 1 × DVI-D
- 1 × DisplayPort V1.2
Integration
SIMATIC Flat Panels in conjunction with SINUMERIK PCU can be used for:
- SINUMERIK 840D sl:
- via IPC to NCU 710.3B PN/NCU 720.3B PN/NCU 730.3B PN
- SINUMERIK ONE
- via IPC to NCU 1740/NCU 1750/NCU 1760
- SINUMERIK MC
- MCU 1720
Visit 6AV7863-4MA10-2NA0
For more our products visit turll.com
| Weight | 8.66 kg |
|---|---|
| Dimensions | 550 × 660 × 275 mm |
