6DR5013-0EM01-0AA0 SIEMENS Exclusive SIPART PS2 Electropneumatic Positioner Original Brand New

6DR5013-0EM01-0AA0 SIEMENS Exclusive SIPART PS2 Electropneumatic Positioner Original Brand New

The SIEMENS SIPART PS2 electropneumatic positioner, part number 6DR5013-0EM01-0AA0, is a highly intelligent and reliable solution for controlling pneumatic valve actuators. Engineered with non-contacting position detection (NCS), this smart positioner ensures wear-free operation while delivering accurate and efficient valve positioning based on 4–20 mA input signals. Housed in a robust aluminum enclosure, it supports both Ex and nEx applications for use in hazardous environments.

This single-acting variant features standard intrinsic safety (Ex i) protection, with optional accessories like SITRANS I200 and I100 isolators for enhanced signal and power integration. It also supports analog position feedback (AOM) and is optionally expandable via plug-in modules such as digital I/O and limit switches. Ideal for both linear and part-turn actuators, SIPART PS2 provides unmatched flexibility and reliability for demanding industrial applications.

Overview

The SIPART PS2 positioner automatically controls the valve position according to process setpoints, utilizing intelligent online and offline diagnostics for proactive maintenance. Diagnostic capabilities can be enhanced with additional pressure sensors, enabling advanced condition monitoring during and between operations.

Design

The SIPART PS2 is built with flexibility and durability in mind. It consists of:

• Base plate with optional inspection window
• Advanced electronics supporting: 4–20 mA, HART, PROFIBUS PA, FOUNDATION Fieldbus
• Non-contacting sensor (NCS) or potentiometer for position feedback
• Pneumatic block with optional gauge block, booster, VDI3847 interface, or solenoid valve
• Mountable on linear or part-turn actuators using dedicated kits

Optional Expansion

SIPART PS2 is modular and supports the following optional functions:

• Analog Output Module (AOM): 4–20 mA analog position feedback
• Digital I/O Module (DIO): 3 digital outputs, 1 digital input, alarm signaling, safety responses
• Inductive Limit Switches (ILS): NAMUR signals with built-in fault indicator
• Mechanical Limit Switches (MLS): Two independent mechanical switches with fault signaling

All modules are electrically isolated and self-signaling in the event of a fault, with easy retrofit installation.

Remote Installation

SIPART PS2 can be remotely mounted apart from the actuator. This enables operation in protected zones when field conditions (vibration, radiation, etc.) exceed the device’s environmental limits.

Product Code: 6DR5013-0EM01-0AA0
