6DR5013-0EN01-0AA0 SIEMENS Exclusive SIPART PS2 Smart Electropneumatic Positioner Original Brand New

6DR5013-0EN01-0AA0 SIEMENS Exclusive SIPART PS2 Electropneumatic Positioner Original Brand New

The SIEMENS 6DR5013-0EN01-0AA0 SIPART PS2 is a high-performance electropneumatic positioner designed for precise and intelligent valve control in industrial automation systems. Engineered with non-contacting (wear-free) position detection (NCS), this device ensures long-term reliability and minimal maintenance. It operates using a 4...20 mA signal and is suitable for single-acting linear or part-turn pneumatic actuators.

With a rugged aluminum enclosure and Ex/nEx protection, it meets high safety requirements, including intrinsic safety (Ex i). It features analog position feedback via the Analog Output Module (AOM), and optional digital expansion modules for flexible integration. Electrical and pneumatic connections are designed for efficient setup, with threads of 1/2" NPT (electrical) and 1/4" NPT (pneumatic).

Overview

SIPART PS2 positioners control pneumatic valves based on setpoint signals and offer intelligent diagnostic capabilities both online and offline. These diagnostics can be expanded with optional pressure sensors, helping to detect potential faults and prevent failure. The positioner ensures high accuracy and adaptability across a wide range of industrial environments.

Design

The SIPART PS2 features a modular structure with robust components including:

• Base plate with or without inspection window
• Electronics for 4–20 mA, HART, PROFIBUS PA, or FOUNDATION Fieldbus
• Pneumatic block with right-side connections for air supply and actuation
• Support for gauge blocks, boosters, and VDI3847 interfaces
• Mountable on linear or part-turn actuators using kits

Optional Modules and Functions

• Analog Output Module (AOM): Provides 4–20 mA feedback
• Digital I/O Module: 3 digital outputs, 1 digital input, alarm and position monitoring
• Inductive Limit Switches (ILS): NAMUR signaling with integrated fault detection
• Mechanical Limit Switches (MLS): Mechanical position monitoring with fault indication

All modules are electrically isolated and retrofittable, with built-in diagnostics for ease of use and system reliability.

Remote Mounting

SIPART PS2 allows separate installation of the positioner and position detection mechanism. This setup is ideal for harsh environments with high vibration, radiation, or magnetic interference. Components are connected via cable (electrical) and tubing (pneumatic), increasing system flexibility.

Product Code: 6DR5013-0EN01-0AA0
