6DR5020-0EM00-0AA0 SIEMENS Exclusive SIPART PS2 Electropneumatic Positioner Original Brand New

6DR5020-0EM00-0AA0 SIEMENS Exclusive SIPART PS2 Electropneumatic Positioner Original Brand New

The SIEMENS 6DR5020-0EM00-0AA0 SIPART PS2 electropneumatic positioner is a smart, reliable solution for precise valve control in industrial applications. Designed for pneumatic linear and part-turn actuators, it operates using a 4...20 mA signal and includes a non-contacting, wear-free position detection system (NCS) to ensure long service life and high accuracy. The robust polycarbonate enclosure makes it suitable for harsh environments, while the Ex i protection standard allows safe use in hazardous areas.

Its fail-safe function ensures depressurization of the actuator in case of electrical auxiliary power failure. With standard configuration (no option modules, manometer block, or boosters), the SIPART PS2 provides cost-effective automation without compromising quality. Optional modules like analog outputs, digital I/O, and limit switches can be retrofitted for greater customization.

Overview

The SIPART PS2 positioner controls valve movement according to the setpoint signal and enables both online and offline diagnostics. Optional pressure sensors extend diagnostic capabilities. The system ensures high-performance control while reducing maintenance costs.

Design

This digital positioner consists of:

• Polycarbonate enclosure with base plate and lid (with/without inspection window)
• Electronics with terminal support for 4–20 mA, HART, PROFIBUS PA, or FOUNDATION Fieldbus
• Non-contacting sensor (NCS) or potentiometer for position feedback
• Pneumatic block for actuating pressure and supply air

The SIPART PS2 supports additional modules:

• Analog Output Module: 4–20 mA position feedback
• Digital I/O Module: 3 outputs, 1 input for limit and fault signaling
• Inductive/Mechanical Limit Switches: NAMUR or mechanical monitoring of actuator limits

All expansion modules are electrically isolated and retrofittable.

Separate Mounting

SIPART PS2 allows remote installation from the actuator, enabling protection from extreme conditions like vibration, radiation, or magnetic fields. Pneumatic and electrical connections are maintained via tubing and cables.

Product Code: 6DR5020-0EM00-0AA0
