The 6DR5113-0NG00-0AA0 SIEMENS SIPART PS2 is a smart electropneumatic positioner that delivers exceptional precision and reliability for controlling valve positions in pneumatic systems. Designed for use with both linear and part-turn actuators, it utilizes a wear-free, non-contacting sensor (NCS) to determine valve position, ensuring long-lasting performance and low maintenance. This unit operates via a 4–20 mA control signal with HART communication protocol and features an aluminum enclosure optimized for demanding industrial environments.

Engineered without a pressure sensor and manometer block, this standard variant includes fail-safe functionality that depressurizes the actuator upon loss of auxiliary power. It is Ex/nEx compliant and offers robust, diagnostics-ready electronics for reliable operation.

Overview

SIPART PS2 positioners automatically control pneumatic valves based on setpoint values. This model supports advanced diagnostic capabilities during both live operations and downtime. It allows enhanced process transparency and predictive maintenance. Pressure sensors can be added to further improve diagnostics.

Design

The SIPART PS2 positioner includes:

• Electronics with screw-type terminals (4–20 mA, HART, PROFIBUS PA, FOUNDATION Fieldbus)
• Non-contacting position feedback (NCS) or potentiometer-based
• Pneumatic block with connections on the right side (G 1/4")
• Optional accessories such as booster, solenoid valve, and VDI3847 interface

It is suitable for direct mounting or remote positioning via cable and tube, allowing installation in protected areas when environmental conditions are harsh (vibration, radiation, etc.).

Optional Modules

SIPART PS2 supports several optional expansions:

• Analog Output Module (AOM): 4–20 mA position feedback
• Digital I/O Module (DIO): 3 digital outputs + 1 digital input for alarms, travel limits, and safety signals
• Inductive Limit Switches (ILS): Two NAMUR-compliant setpoints with fault signaling
• Mechanical Limit Switches (MLS): Mechanical switching with built-in fault indicators

All modules are electrically isolated, self-signaling, and retrofittable.

Product Code: 6DR5113-0NG00-0AA0
