6DR7112-0NN11-1BA0 SIEMENS Exclusive SIPART PS100 Electropneumatic Positioner Original Brand New

Model / SKU6DR7112-0NN11-1BA0

SIEMENS SIPART PS100 electropneumatic positioner for linear or part-turn actuators with 4–20 mA input, AO feedback, and easy commissioning for reliable valve automation.

$3,667.49
In stockShips in 1–3 business days
  • ConditionOriginal Brand New
  • Warranty12 months
Request bulk quoteAsk on WhatsApp
  • Genuine Products
  • Up to 1-Year Warranty
  • Global Shipping
  • Secure Payment
  • PI / Bank Transfer Available
  • Bulk Quote Support

Description

6DR7112-0NN11-1BA0 SIEMENS Exclusive SIPART PS100 Electropneumatic Positioner Original Brand New

SIPART PS100 electropneumatic positioner with a 4 to 20 mA input automates control valves. The positioner enclosure has an aluminum lid without a viewing window. It is suitable for single and double-acting linear and part-turn actuators. Positioner knowledge is not required. Commissioning is done at the push of a button. Double-acting Without explosion protection 2-wire, 4 ... 20 mA without device option 1 with analog output (AO) 4 ... 20 mA Thread of the lower cable entry: M20 x 1.5 / with cable gland plastic Thread of the upper cable entry: M20x1.5 / with cable gland plastic with pneumatic thread 1/4-18 NPT without pressure gauge block Without other designs

The 6DR7112-0NN11-1BA0 SIEMENS SIPART PS100 is a high-performance electropneumatic positioner designed to automate control valves efficiently and with minimal setup requirements. Built with robust components and an aluminum enclosure without a viewing window, this positioner is suited for both single and double-acting linear and part-turn actuators. Engineered to simplify commissioning, the SIPART PS100 can be initialized with a single button press—eliminating the need for expert-level configuration knowledge.

Equipped with a 4 to 20 mA analog input signal and offering an optional analog output for feedback, it provides precise and reliable control in a wide range of industrial automation systems. The device features plastic cable glands on both top and bottom entries (M20 x 1.5 thread) and a 1/4-18 NPT pneumatic interface. Built without explosion protection, this model is ideal for non-hazardous environments that demand high operational reliability and low maintenance.

Overview

The SIPART PS100 electropneumatic positioner is used for precise regulation of pneumatic valve or damper positioning. It receives a setpoint via analog input and adjusts the actuator position accordingly. Its streamlined operation enhances system performance and ensures consistency in control processes across varied applications.

Design

This model consists of a well-structured enclosure housing the following components:

  • Base plate and aluminum lid
  • Integrated pneumatic block located on the right-hand side
  • Electronics with wear-free position detection
  • Electrical connection ports on the left-hand side

The positioner shaft is positioned underneath and connects to actuators via a compatible mounting kit. Its design supports accurate spindle tracking for linear and rotary movement.

Optional features include:

  • Analog Output (AO) 4 to 20 mA – provides feedback on valve position
  • Digital Input/Output for position limit monitoring and alarm output
  • HART communication protocol support for diagnostics and configuration

Product Code: 6DR7112-0NN11-1BA0

More Siemens products at Turll.com

Specifications

SKU / Model6DR7112-0NN11-1BA0
Weight1.055 kg
