6ES7660-8DP01-1DC2 SIEMENS Exclusive SIMATIC IPC547J PCS 7 OS Client Original Brand New

6ES7660-8DP01-1DC2 SIEMENS Exclusive SIMATIC IPC547J PCS 7 OS Client Original Brand New

The SIEMENS 6ES7660-8DP01-1DC2 is a powerful SIMATIC IPC547J rackmount PC designed for PCS 7 OS Client applications. Powered by an Intel Core i7-10700E processor with 8 cores and 16 threads, this 4U rack PC delivers exceptional performance for industrial control systems. The unit comes preinstalled with PCS 7 V9.1 SP2 and Windows 10 IoT Enterprise 2019 LTSC, making it ideal for seamless integration into the PCS 7 environment. It features a 480 GB SSD for high-speed storage and 16 GB DDR4 RAM in a dual-channel configuration for reliable multitasking.

Overview

6ES7660-8DP01-1DC2 Engineered for continuous industrial operation, the IPC547J offers a robust design with a blue-chromated enclosure. 6ES7660-8DP01-1DC2 can withstand up to 5 g shock and 0.5 g vibration, ensuring dependable performance in harsh conditions. Its extensive connectivity includes three Gbit LAN ports, multiple USB interfaces, and support for multi-monitor setups. The system features seven expansion slots (5x PCIe, 2x PCI), providing flexibility for various industrial applications. With advanced temperature and fan monitoring plus watchdog functionality, this unit guarantees high availability in critical control systems.

• Intel Core i7-10700E (8 cores/16 threads, 2.9 GHz base, 4.5 GHz turbo, 16 MB cache)
• Preinstalled PCS 7 V9.1 SP2 with Windows 10 IoT Enterprise 2019 LTSC (64-bit)
• 480 GB SSD 2.5″ SATA for internal installation
• 16 GB DDR4 SDRAM (2x 8 GB), Dual Channel
• Advanced cooling system with temperature and fan monitoring
• Interfaces: 3x Gbit LAN (RJ45), 1x DVI-D, 2x DisplayPort, 1x COM, Audio
• USB Ports: 6x USB 3.1 Gen2 (rear), 2x USB 3.1 Gen1 (front), 2x USB 2.0 (internal)
• 7 expansion slots: 5x PCIe, 2x PCI
• Industrial-grade 100/240 V AC power supply with USA power cord

Design

• Industrial 19″ 4U rackmount enclosure with enhanced durability
• Optimized for continuous 24/7 operation in industrial settings
• Flexible expansion options for diverse control system requirements
• Supports multi-monitor configurations for control room applications
• Comprehensive protection against mechanical and thermal stress
• Preconfigured with system restore via USB flash drive
