6ES7823-1FA05-0YA5 Siemens SIMATIC S7-PLCSIM Advanced V6.0 Original Brand New
$3,813.38
6ES7823-1FA05-0YA5
Siemens SIMATIC S7-PLCSIM Advanced V6.0, floating license; option for simulation of S7-1500, ET 200SP/pro & software/open controller; license valid for 2 of max. 16 possible PLC instances; software and documentation on DVD; license key on USB flash drive; class A; software 1 language: en; documentation 2 languages: de,en – – for system requirements specification, see www.siemens.com/compatool
[ez-toc]
Overview
With SIMATIC S7-PLCSIM Advanced, digital twins can be used for simulation of S7-1500 and ET 200SP controllers and for extensive function simulation.
The digital twins can also be tested and validated in conjunction with a plant/machine. An extensive API is available for interfacing plant/machine simulations.
Highlights of SIMATIC S7-PLCSIM Advanced V6.0
New CPU types
- Support of Software Controllers and Open Controllers from V30.0, including synchronous SIMATIC ODK
- Support of all new S7-1500 CPUs with firmware 3.1 (incl. SIPLUS)
Compatibility
S7-PLCSIM Advanced now supports TIA Portal projects of versions V14 to V19 and CPU firmware versions V1.8 – V3.1.
The user interface of S7-PLCSIM V19 is also intended for use with S7-PLCSIM Advanced V6.0.
Licensing
- The engineering software can be installed on multiple computers. The number of existing licenses determines the number of computers on which the software can be used simultaneously (floating license). For each license, the use of two simultaneously started S7-PLCSIM Advanced instances is permitted.
- For users of the previous versions 1.0/2.x/3.0/4.x/5.0, an upgrade to version 6.0 is offered.
- In addition, it is possible to purchase the software as an annual subscription.
- It is possible to conclude Software Update Service (SUS) contracts.
You can find more information on the Software Update Service, license types, Online Software Delivery and handling your SW licenses with the Automation License Manager under this link.
Benefits
- A realistic function test of the STEP 7 TIA Portal program allows early fault detection and validation of functionality:
- High quality of the automation project at a very early point in time
- Shortening of commissioning time at the customer plant
- Reduction in time-to-production
- Reduction of risks during commissioning
- Early operator training possible using simulated controllers and a connected HMI device/HMI simulation
- Increased efficiency through testing and optimization of program parts
- Quick replacement of machine components (migration) and easy enhancement of existing plants with the help of the virtual model of the plant/machine
Application
During the configuration and engineering phase with STEP 7 in the TIA Portal, S7-1500/ET 200SP CPU hardware is no longer required with S7-PLCSIM Advanced in order to carry out an extensive function simulation. S7-PLCSIM Advanced can be used to generate digital twins for function validation which can be tested and validated either standalone or in conjunction with a plant/machine. In this way, extensive co-simulation solutions can be set up, e.g. with the SIMIT Simulation Platform, Process Simulate, Plant Simulation or NX Mechatronics Concept Designer.
Function
Simulation and validation of the controller functionality of S7-1500/ET 200SP CPU for
- Verification of the user program (TIA Portal)
- Automatic testing of the STEP 7 program
- Software-in-the-Loop simulation for virtual commissioning of machine tools/production machines, production cells and production lines in a plant.
Several instances and thus the interaction of multiple PLCs are supported. In addition, structures with distributed instances are also supported (e.g.: PLC 1 and PLC 2 run on PC 1; PLC 3 runs on PC 2 and the plant/machine simulation runs on PC 3). An extensive API is available for interfacing plant/machine simulations to S7-PLCSIM Advanced.
6ES7823-1FA05-0YA5
Siemens SIMATIC S7-PLCSIM Advanced V6.0, floating license; option for simulation of S7-1500, ET 200SP/pro & software/open controller; license valid for 2 of max. 16 possible PLC instances; software and documentation on DVD; license key on USB flash drive; class A; software 1 language: en; documentation 2 languages: de,en – – for system requirements specification, see www.siemens.com/compatool
Visit 6ES7823-1FA05-0YA5
For more our products visit turll.com
| Weight | 0.186 kg |
|---|---|
| Dimensions | 174.00 × 190.00 × 34.00 mm |
