6GK5524-8GS00-4AR2 – Ultimate Siemens SCALANCE XR524-8C Modular Industrial Ethernet Switch
$16,707.83
6GK5524-8GS00-4AR2 XR524-8C rack switch with 24 Gigabit RJ45 ports, 8 combo SFP slots, dual AC feeds, PROFINET IO diagnostics, and optional Layer 3 routing via Key-Plug.
6GK5524-8GS00-4AR2 – Ultimate Siemens SCALANCE XR524-8C Modular Industrial Ethernet Switch
The Layer 3-enabled SCALANCE XR-500 series delivers high-performance switches for electrical and optical topologies with up to 10 Gbps. Designed for 19″ control cabinets, it offers up to 48 interfaces for seamless network integration.
Overview
The Siemens SCALANCE XR524-8C combines 24 fixed Gigabit RJ45 ports and 8 combo SFP slots in a robust rack-mount design. Dual 230 V AC inputs ensure power redundancy, while PROFINET IO diagnostics and a Key-Plug module provide optional Layer 3 routing and fast device replacement.
Key Features
- 24× 10/100/1000 Mbps RJ45 ports
- 8× 100/1000 Mbps combo SFP slots
- Dual 230 V AC power inputs via IEC connectors
- Optional Layer 3 routing with Key-Plug module
- PROFINET IO diagnostics (Conformance Class B)
- Redundancy: MRP, HRP, HSR, PRP, RSTP, MSTP
- VLAN, IGMP snooping, ACL, SNMP, IEEE 802.1X
- Front LEDs, SELECT/SET pushbutton, floating alarm contact
- Console port for local configuration
- IP20 metal housing; fanless operation
- Operating range: –25 °C to +60 °C
- Dimensions: 449 × 305 × 44 mm; Weight: ~5.42 kg
- C-PLUG memory module for quick backup and replacement
Product Code: 6GK5524-8GS00-4AR2
More Siemens products at Turll.com
| Weight | 5.42 kg |
|---|---|
| Dimensions | 449 × 305 × 87.2 mm |
