The 6SE6400-3TC07-5ED0 SIEMENS output reactor is designed for reliable performance in demanding power conversion environments. As part of the MICROMASTER 4 series, this component supports stable operation in applications where longer motor cables and rapidly switching power electronics place additional stress on the system. Rated for 380–480 V three-phase operation, the reactor is capable of handling 75 A in high overload mode and 90 A in low overload mode, ensuring suitability for a wide range of industrial requirements. Its construction demonstrates Siemens’ commitment to delivering components that improve efficiency, enhance system durability, and support long-term operational stability.

The output reactor is engineered to reduce voltage rise rates and mitigate undesirable current peaks that occur during inverter switching events. In systems with long motor cables, the cable capacitance reverses polarity rapidly with each switching cycle. This process can cause substantial peak currents that stress the inverter. By moderating these effects, the reactor protects sensitive components and helps maintain dependable functionality. The result is an improved operating environment with better thermal behavior and reduced electrical strain.

This model is particularly valuable for installations involving PM240-2 Power Modules, frame size FSG. When integrated correctly, it allows for smoother system behavior and lower harmonic influence. Operators benefit from increased motor cable flexibility and reduced electromagnetic interference, enabling cleaner signals and more controlled operation. Installation guidelines recommend placing the reactor as close as possible to the power module, helping ensure optimal attenuation and maximum protection.

Overview

The output reactor supports PM240-2 power modules and enhances inverter performance by reducing dv/dt levels and limiting current peaks. It enables longer cable lengths while protecting sensitive components from switching-induced stress.

Its inductive design slows the polarity reversal of cable capacitance, ensuring more stable operation in fast-switching environments. This helps extend equipment life and improve efficiency across various industrial systems.

• Maximum output frequency: 150 Hz
• Maximum pulse frequency: 4 kHz
• Reactor should be installed close to the power module

Product Code:6SE6400-3TC07-5ED0
