6XV1870-3QH60 Siemens Industrial Ethernet TP Cord Original Brand New
6XV1870-3QH60 Siemens Industrial Ethernet TP Cord Original Brand New - Image 2
6XV1870-3QH60 Siemens Industrial Ethernet TP Cord Original Brand New - Image 3
6XV1870-3QH60 Siemens Industrial Ethernet TP Cord Original Brand New - Image 4

6XV1870-3QH60 Siemens Industrial Ethernet TP Cord Original Brand New

Model / SKU6XV1870-3QH60

6XV1870-3QH60 SiemensĀ

Industrial Ethernet TP Cord RJ45/RJ45, CAT 6A, TP cable 4×2, pre-assembled with 2 RJ45 connectors, length 6 m.
Original price was: $75.65.Current price is: $31.74.
Available on backorder
  • ConditionOriginal Brand New
  • Warranty12 months

Backorder available Ā· Factory lead time 2ā€“3 weeks.

Request bulk quoteAsk on WhatsApp
  • Genuine Products
  • Up to 1-Year Warranty
  • Global Shipping
  • Secure Payment
  • PI / Bank Transfer Available
  • Bulk Quote Support

Description

Overview

  • Patch cable, available fully assembled
  • With 4Ā xĀ 2 cores for 10/100/1Ā 000Ā Mbps Ethernet
  • Small cable diameter
  • Cat6AĀ (4Ā xĀ 2) of the ISO/IECĀ 11801 and ENĀ 50173 international cabling standards

Benefits

  • Simple connection of terminals with an RJ45 interface to the interference-proof Industrial Ethernet FastConnect cabling system (10/100/1000Ā Mbps)
  • Quick and error-free commissioning thanks to pre-assembled, factory-tested patch cables
  • Simple cable laying due to small cable diameter
  • Silicone-free, therefore suitable for use in the automotive industry (for example on paint lines)
  • Color-coded RJ45 plugs for differentiation between twisted and non-twisted lines
    • Twisted: RJ45 plug red on both sides
    • Non-twisted: RJ45 plug green on both sides
  • Easy visual differentiation of data connections thanks to different colors of cable sheaths

Design

  • 4Ā xĀ 2 cores for 10/100/1000Ā Mbps transfer rate
  • Two cores with two dummy elements twisted into a pair
  • Each pair is encased in plastic film and shielded with a plastic-clad aluminum foil
  • Outer protective braided shield around all pairs comprising tinned copper wires
  • Plastic sheath (PVC) available in different sheath colors

IE TP cord is available with TP cord 4Ā xĀ 2 as pre-assembled cables in the following variants:

  • IE TP cord RJ45/RJ45
    with 2 x RJ45 plugs
  • IE TP XP cord RJ45/RJ45
    with 2 x RJ45 plugs, send and receive cables are twisted.

Function

The flexibility of the cable ensures easy installation, for example in a control cabinet, or to connect equipment in a control room. The maximum length of an IE TP cord is 10Ā m in case of a structured set-up. In case of direct point-to-point connections, lengths of up to 50Ā m are possible.

6XV1870-3QH60 SiemensĀ

Industrial Ethernet TP Cord RJ45/RJ45, CAT 6A, TP cable 4x2, pre-assembled with 2 RJ45 connectors, length 6 m.



Specifications

SKU / Model6XV1870-3QH60
Weight0.217 kg
Dimensions200 × 207 × 45 mm
