7MF1575-1DA10 SIEMENS Exclusive SITRANS LH300 Hydrostatic Level Transmitter Original Brand New

7MF1575-1DA10 SIEMENS Exclusive SITRANS LH300 Hydrostatic Level Transmitter Original Brand New

The SIEMENS 7MF1575-1DA10 SITRANS LH300 is a high-quality hydrostatic level transmitter designed for precise liquid level measurement in industrial and environmental applications. This submersible transmitter operates with a two-wire connection and a 4...20 mA output signal, making it ideal for reliable integration into process control systems. With its measuring cell made from 99.6% purity Al2O3 ceramic and robust stainless steel 316L housing, the transmitter is engineered to deliver long-lasting performance even in demanding conditions. The protective cap, crafted from PPE with FKM sealing, ensures dependable resistance against external influences and provides safe immersion in diverse liquid environments.

This model is equipped with a fixed-mounted 10-meter cable, ensuring easy installation and dependable signal transmission. The hydrostatic pressure measurement principle allows accurate monitoring of liquid levels in tanks, containers, channels, and dams. Built for versatility, the SITRANS LH300 can be supplied in different measuring ranges and can also be configured with explosion protection options when required.

Overview

The SITRANS LH300 series transmitters are optimized for hydrostatic level measurement in water supply, wastewater treatment, and industrial process applications. Each sensor features a compact construction that supports seamless integration into existing systems. Accessories such as cable boxes and anchoring clamps are available to further simplify installation and enhance system reliability.

Design

At the core of the device is a ceramic sensing element incorporating a Wheatstone resistance bridge, delivering stable and accurate pressure conversion. The sensor, electronic circuit, and cable are housed together in a corrosion-resistant stainless steel enclosure with small dimensions, making it both durable and easy to handle. The cable includes a vent tube equipped with a humidity filter, which prevents condensation build-up and ensures consistent measurement accuracy. To further extend durability, the diaphragm is protected by a strong cap that shields it from mechanical damage and environmental stressors.

The transmitter is also temperature-compensated, maintaining stable accuracy over a wide operating range. With its advanced design, rugged construction, and precise measurement capabilities, the SIEMENS SITRANS LH300 7MF1575-1DA10 provides a dependable solution for industries requiring consistent level monitoring in challenging operating environments.

Product Code: 7MF1575-1DA10
