SIEMENS

3RM1007-1AA14

Name: Siemens 3RM1007-1AA14 Direct Starter 3RM1 Motor Starter 500V, 0.55–3 kW, 1.6–7A, 110–230V AC Original Brand New
Brand: SIEMENS
SKU: 3RM1007-1AA14

Siemens 3RM1007-1AA14 Direct Starter 3RM1 Motor Starter 500V, 0.55–3 kW, 1.6–7A, 110–230V AC Original Brand New

Enlarge

Price on request

USD

Availability on request

Estimated 2–8 weeks; confirm by quote

Condition: Original brand new
Warranty: 12 months

Save 2% on merchandise with bank transfer

Request price & availability

Review shipping and applicable charges at checkout. Dispatch time excludes transit.

Select a configuration to check its price, availability and supply terms.

Send your model and quantity. We will confirm the price and lead time.

Specifications & documents ↓

Ask about this model on WhatsApp

Payments, shipping & warranty

PayPal
Bank transfer

See available methods at checkout.Payment guide →

PRODUCT DATA

Specifications

Check the full model number and every required specification.

Listed product specifications
SKU / model	3RM1007-1AA14
Brand	SIEMENS
product brand name	SIRIUS
product category	Motor starter
product designation	Direct-on-line starter
design of the product	with electronic overload protection
product type designation	3RM1
trip class	CLASS 10A
equipment variant acc. to IEC 60947-4-2	3
● intrinsic device protection	Yes
● for power supply reverse polarity protection	No
suitability for operation device connector 3ZY12	No
power loss [W] for rated value of the current at AC in hot operating state per pole	1.13 W
insulation voltage rated value	500 V
overvoltage category	III
surge voltage resistance rated value	6 kV
maximum permissible voltage for safe isolation	-
● between main and auxiliary circuit	500 V
● between control and auxiliary circuit	250 V
shock resistance	6g / 11 ms
vibration resistance	1 ... 6 Hz, 15 mm; 20 m/s², 500 Hz
operating frequency maximum	1 1/s
mechanical service life (switching cycles) typical	30 000 000
reference code acc. to IEC 81346-2	Q
product function	-
● direct start	Yes
● reverse starting	No
product function short circuit protection	No
EMC emitted interference acc. to IEC 60947-1	class A
EMC immunity acc. to IEC 60947-1	Class A
conducted interference	-
● due to burst acc. to IEC 61000-4-4	3 kV / 5 kHz
● due to conductor-earth surge acc. to IEC 61000-4-5	2 kV
● due to conductor-conductor surge acc. to IEC 61000-4-5	1 kV
● due to high-frequency radiation acc. to IEC 61000-4-6	10 V
field-based interference acc. to IEC 61000-4-3	10 V/m
electrostatic discharge acc. to IEC 61000-4-2	4 kV contact discharge / 8 kV air discharge
conducted HF interference emissions acc. to CISPR11	Class B for domestic, business and commercial environments; Class A for industrial environments at 110 V DC
field-bound HF interference emission acc. to CISPR11	Class B for domestic, business and commercial environments; Class A for industrial environments at 110 V DC
protection class IP on the front acc. to IEC 60529	IP20
touch protection on the front acc. to IEC 60529	finger-safe
number of poles for main current circuit	3
design of the switching contact	Hybrid
design of the switching contact as NO contact for signaling function	OUT, electronic, 24 V DC, 15 mA
adjustable current response value current of the current-dependent overload release	1.6 ... 7 A
minimum load [%]	20 %; from set rated current
type of the motor protection	solid-state
operating voltage rated value	48 ... 500 V
relative symmetrical tolerance of the operating voltage	10 %
operating frequency 1 rated value	50 Hz
operating frequency 2 rated value	60 Hz
relative symmetrical tolerance of the operating frequency	10 %
● at AC at 400 V rated value	7 A
● at AC-3 at 400 V rated value	7 A
● at AC-53a at 400 V at ambient temperature 40 °C rated value	7 A
ampacity when starting maximum	56 A
operating power for 3-phase motors at 400 V at 50 Hz	0.55 ... 3 kW
derating temperature	40 °C
● at DC rated value	110 V
input voltage at digital input	-
● at AC rated value	110 V
● with signal <0> at AC	0 ... 40 V
● for signal <1> at AC	93 ... 253 V
input current at digital input	-
● for signal <1> at DC	1.5 mA
● with signal <0> at DC	0.25 mA
input current at digital input with signal <0> at AC	-
input current at digital input for signal <1> at AC	-
● at 110 V	1.1 mA
● at 230 V	2.3 mA
number of CO contacts for auxiliary contacts	1
operational current of auxiliary contacts at AC-15 at 230 V maximum	3 A
operational current of auxiliary contacts at DC-13 at 24 V maximum	1 A
type of voltage of the control supply voltage	AC/DC
control supply voltage at AC	-
● at 50 Hz rated value	110 ... 230 V
● at 60 Hz rated value	110 ... 230 V
relative negative tolerance of the control supply voltage at AC at 60 Hz	15 %
relative positive tolerance of the control supply voltage at AC at 60 Hz	10 %
control supply voltage 1 at AC	-
● at 50 Hz	110 ... 230 V
● at 60 Hz	110 ... 230 V
control supply voltage frequency	-
● 1 rated value	50 Hz
● 2 rated value	60 Hz
relative negative tolerance of the control supply voltage at DC	15 %
relative positive tolerance of the control supply voltage at DC	10 %
control supply voltage 1 at DC rated value	110 V
operating range factor control supply voltage rated value at DC	-
operating range factor control supply voltage rated value at AC at 50 Hz	-
operating range factor control supply voltage rated value at AC at 60 Hz	-
● initial value	0.85
● full-scale value	1.1
control current at AC	-
● at 110 V in standby mode of operation	16 mA
● at 230 V in standby mode of operation	9 mA
● at 110 V when switching on	55 mA
● at 230 V when switching on	33 mA
● at 110 V during operation	36 mA
● at 230 V during operation	22 mA
control current at DC	-
● in standby mode of operation	6 mA
● when switching on	15 mA
power loss [W] in auxiliary and control circuit	-
● in switching state OFF	-
● in switching state ON	-
— with bypass circuit	5.06 W
ON-delay time	60 ... 90 ms
OFF-delay time	60 ... 90 ms
operational current	-
● at 40 °C rated value	7 A
● at 50 °C rated value	6.1 A
● at 55 °C rated value	5.2 A
● at 60 °C rated value	4.6 A
mounting position	vertical, horizontal, standing (observe derating)
fastening method	screw and snap-on mounting onto 35 mm standard mounting rail
required spacing	-
● with side-by-side mounting	-
● for grounded parts	-
— forwards	0 mm
— backwards	0 mm
— upwards	50 mm
— at the side	3.5 mm
— downwards	50 mm
installation altitude at height above sea level maximum	4 000 m; For derating see manual
ambient temperature	-
● during operation	-25 ... +60 °C
● during storage	-40 ... +70 °C
● during transport	-40 ... +70 °C
environmental category during operation acc. to IEC 60721	3K6 (no ice formation, only occasional condensation), 3C3 (no salt mist), 3S2 (sand must not get into the devices), 3M6
relative humidity during operation	10 ... 95 %
air pressure acc. to SN 31205	900 ... 1 060 hPa
protocol is supported	-
● PROFINET IO protocol	No
● PROFIsafe protocol	No
product function bus communication	No
protocol is supported AS-Interface protocol	No
type of electrical connection	screw-type terminals for main circuit, screw-type terminals for control circuit
● for main current circuit	screw-type terminals
● for auxiliary and control circuit	screw-type terminals
wire length for motor unshielded maximum	100 m
● at AWG cables for main contacts	1x (20 ... 12), 2x (20 ... 14)
connectable conductor cross-section for main contacts	-
connectable conductor cross-section for auxiliary contacts	-
● solid or stranded	0.5 ... 2.5 mm²
● finely stranded with core end processing	0.5 ... 2.5 mm²
type of connectable conductor cross-sections	-
— solid	1x (0,5 ... 2,5 mm²), 2x (1,0 ... 1,5 mm²)
— finely stranded with core end processing	1x (0.5 ... 2.5 mm²), 2x (0.5 ... 1 mm²)
● at AWG cables for auxiliary contacts	1x (20 ... 14), 2x (18 ... 16)
AWG number as coded connectable conductor cross section	-
● for main contacts	20 ... 12
● for auxiliary contacts	20 ... 14
yielded mechanical performance [hp]	-
● for single-phase AC motor	-
— at 110/120 V rated value	0.25 hp
— at 230 V rated value	0.5 hp
● for 3-phase AC motor	-
— at 200/208 V rated value	1 hp
— at 220/230 V rated value	1.5 hp
— at 460/480 V rated value	3 hp
operating voltage at AC	-
● according to UL rated value	480 V
● according to CSA rated value	400 V
Test Certificates	Railway other
last modified:	11/3/2021
Net weight	0.323 kg
Package dimensions (L × W × H)	36.00 × 109.00 × 167.00 mm

No public document is linked for this model.

Ask for technical documentation

Description

Overview

The Siemens 3RM1007-1AA14 Direct Starter is a compact and reliable motor starter designed for efficient motor control and protection. Part of the Siemens 3RM1 series, this direct starter supports motor power ranges from 0.55 to 3 kW and operates at up to 500 V. With a wide control voltage range of 110–230 V AC and durable screw terminals, it ensures easy installation and dependable performance in industrial and commercial applications.

Benefit

Space Efficiency: Its solid-state, compact design means fewer components and smaller footprint, leading to reduced control cabinet costs.
Long Service Life: As a solid-state device, it has virtually no mechanical wear, offering a significantly longer operational life than electromechanical starters.
Versatile Control: The wide-range 110-230 V AC control voltage allows for global usability and simplifies wiring across different supply systems.
Integrated Protection: The unit provides electronic overload protection for the motor (within the 1.6-7 A range), ensuring maximum motor protection and preventing costly damage.
Simplified Installation: Secure and familiar screw terminals make wiring and commissioning straightforward and reliable.

Function

Direct-on-line motor starting
Motor current control within 1.6–7 A range
Supports stable motor operation under varying loads
Designed for integration into control panels and automation systems

Technical Specification

Manufacturer: Siemens
Product Number: 3RM1007-1AA14
Product Type: Direct Starter
Series: 3RM1
Rated Voltage: Up to 500 V
Motor Power Range: 0.55 – 3 kW
Current Range: 1.6 – 7 A
Control Voltage: 110 – 230 V AC
Connection Type: Screw terminals
