Siemens 3SU1150-4BF11-1BA0 RONIS Key-Operated Switch, 22mm, Metal, 2 Keys, 2 Positions
Siemens 3SU1150-4BF11-1BA0 RONIS Key-Operated Switch, 22mm, Metal, 2 Keys, 2 Positions
Siemens 3SU1150-4BF11-1BA0 RONIS Key-Operated Switch, 22mm, Metal, 2 Keys, 2 Positions
Siemens 3SU1150-4BF11-1BA0 RONIS Key-Operated Switch, 22mm, Metal, 2 Keys, 2 Positions
Siemens 3SU1150-4BF11-1BA0 RONIS Key-Operated Switch, 22mm, Metal, 2 Keys, 2 Positions
Siemens 3SU1150-4BF11-1BA0 RONIS Key-Operated Switch, 22mm, Metal, 2 Keys, 2 Positions

SIEMENS

Siemens 3SU1150-4BF11-1BA0 RONIS Key-Operated Switch, 22mm, Metal, 2 Keys, 2 Positions Original Brand New

Model / SKU3SU1150-4BF11-1BA0

RONIS key-operated switch, 22 mm, round metal design, lock number SB30, with 2 keys, 2 switch positions O-I, latching, 90° actuating angle, 1 NO, screw terminal. Supports special locks SB31, 421, 455.

Original price was: $37.77.Current price is: $17.29.
In stockShips in 1–3 business days
  • ConditionOriginal Brand New
  • Warranty12 months
Request bulk quoteAsk on WhatsApp
  • Genuine Products
  • Up to 1-Year Warranty
  • Global Shipping
  • Secure Payment
  • PI / Bank Transfer Available
  • Bulk Quote Support

Description

Overview

The Siemens 3SU1150-4BF11-1BA0 is a highly reliable component in the SIRIUS ACT control and signaling device range. This specific unit is a robust, 22 mm round, metal key-operated switch designed for secure and deliberate machine control. It utilizes a RONIS lock system with the common lock number SB30 and is supplied with two keys. Its shiny metal design ensures durability and a professional aesthetic in industrial panels.

Key Features & Benefit

  • Enhanced Security: The specific RONIS SB30 lock ensures only authorized personnel can operate or override machine functions, minimizing risk and ensuring compliance.

  • Industrial Durability: Constructed from metal with a shiny finish, it withstands harsh industrial environments, resisting wear, tear, and corrosion.

  • Simple Installation: The standard 22 mm diameter and included holder make it fully compatible with existing control panels and modular systems.

  • Reliable Connection: Screw terminals provide a robust, vibration-proof electrical connection suitable for long-term industrial use.

  • Modular System: Part of the flexible SIRIUS ACT system, allowing for easy expansion or change of contact blocks if needed (e.g., adding an NC contact).

Function & Application

Ideal for industrial and commercial control panels, machinery, and safety devices where secure key access is required. It provides reliable switching with controlled access to prevent unauthorized operation. Perfect for machine control, factory automation, and secure access systems.

Download

Datasheet in PDF

Visit 3SU1150-4BF11-1BA0 for more detail info

For more our products visit turll



Specifications

SKU / Model3SU1150-4BF11-1BA0
BrandSIEMENS
product brand nameSIRIUS ACT
product designationKey-operated switches
design of the productComplete unit
product type designation3SU1
product lineMetal, shiny, 22 mm
manufacturer's article number-
● of included key3SU1950-0FB80-0AA0
● of supplied contact module3SU1400-1AA10-1BA0
● of supplied contact module at position 13SU1400-1AA10-1BA0
● of the supplied holder3SU1550-0AA10-0AA0
● of the supplied actuator3SU1050-4BF11-0AA0
shape of the enclosure frontround
number of command points1
principle of operation of the actuating elementlatching, 90° (10:30 h/13:30 h)
product extension optional light sourceNo
color of the actuating elementsilver
material of the actuating elementmetal
shape of the actuating elementKey
outer diameter of the actuating element29.5 mm
number of contact modules1
number of switching positions2
switch position for key distractionO+I
actuating angle-
● clockwise90°
lock makeRONIS
key numberSB30
product component front ringYes
design of the front ringStandard
material of the front ringMetal, high gloss
color of the front ringsilver
material of the holderMetal
product function positive openingNo
product component light sourceNo
insulation voltage rated value500 V
degree of pollution3
type of voltage of the operating voltageAC/DC
surge voltage resistance rated value6 kV
protection class IPIP66, IP67, IP69(IP69K)
● of the terminalIP20
degree of protection NEMA rating1, 2, 3, 3R, 4, 4X, 12, 13
shock resistance-
● acc. to IEC 60068-2-27Sinusoidal half-wave 50g / 11 ms
vibration resistance-
● acc. to IEC 60068-2-610 ... 500 Hz: 5g
operating frequency maximum1 800 1/h
mechanical service life (switching cycles) typical300 000
electrical endurance (switching cycles) typical10 000 000
thermal current10 A
reference code acc. to IEC 81346-2S
continuous current of the C characteristic MCB10 A; for a short-circuit current smaller than 400 A
continuous current of the quick DIAZED fuse link10 A
continuous current of the DIAZED fuse link gG10 A
operating voltage-
● rated value5 ... 500 V
● at AC-
— at 50 Hz rated value5 ... 500 V
— at 60 Hz rated value5 ... 500 V
● at DC rated value5 ... 500 V
contact reliabilityOne maloperation per 100 million (17 V, 5 mA), one maloperation per 10 million (5 V, 1 mA)
design of the contact of auxiliary contactsSilver alloy
number of NC contacts for auxiliary contacts0
number of NO contacts for auxiliary contacts1
type of electrical connection-
type of connectable conductor cross-sections-
● solid with core end processing2x (0.5 ... 0.75 mm²)
● solid without core end processing2x (1.0 ... 1.5 mm²)
● finely stranded with core end processing2x (0.5 ... 1.5 mm²)
● finely stranded without core end processing2x (1,0 ... 1,5 mm²)
● at AWG cables2x (18 ... 14)
tightening torque of the screws in the bracket1 ... 1.2 N·m
tightening torque for auxiliary contacts with screw-type terminals0.8 ... 0.9 N·m
ambient temperature-
● during operation-25 ... +70 °C
● during storage-40 ... +80 °C
environmental category during operation acc. to IEC 607213M6, 3S2, 3B2, 3C3, 3K6 (with relative air humidity of 10 ... 95 %, no condensation in operation permitted for all devices behind front panel)
fastening method-
● of modules and accessoriesFront plate mounting
shape of the installation openinground
mounting diameter22.3 mm
positive tolerance of installation diameter0.4 mm
mounting height49.4 mm
installation width29.5 mm
installation depth49.7 mm
Test CertificatesMarine / Shipping
last modified:10/23/2021
Weight0.129 kg
