LED module with integrated LED 24 V AC/DC, white, spring-loaded terminal, front plate mounting. Minimum order quantity 5 or a multiple thereof.
The Siemens 3SU1401-1BB60-3AA0 is a high-quality LED module designed for reliable signaling performance in industrial control applications. Featuring an integrated LED, 24 V AC/DC operation, and a crisp white illumination, this module ensures optimal visibility and long-lasting functionality. Built with a spring-loaded terminal connection and optimized for front plate mounting, it delivers simple installation and exceptional durability—ideal for modern automation systems.
Minimum order quantity: 5 units or multiples of 5.
Maximum Clarity: The bright white LED ensures excellent visibility and clear operational status indication.
Simplified Installation: Spring-loaded terminals allow for quick, tool-free wiring, significantly reducing installation time and labor costs.
Universal Compatibility: Designed to operate on both AC and DC 24V power, providing flexibility across various electrical systems.
Vibration Resistance: The spring-loaded connection technology offers high contact reliability, even in harsh industrial environments with frequent vibration.
Long-Term Reliability: Integrated LED technology provides a long service life, minimizing the need for replacement and maintenance.
Voltage Rating: 24 V AC/DC
Color: White LED
Connection Type: Spring-loaded terminal
Design: Front plate mounting for easy integration
Integrated LED for simplified setup
High efficiency and stable illumination output
Ideal for operator panels, control stations, and machine interfaces
Minimum order quantity: 5 or multiples thereof
Visit 3SU1401-1BB60-3AA0 for more detail info
For more our products visit turll
| SKU / Model | 3SU1401-1BB60-3AA0 |
|---|---|
| Brand | SIEMENS |
| product brand name | SIRIUS ACT |
| product designation | LED module |
| product type designation | 3SU1 |
| product component | - |
| ● diode | Yes |
| ● lamp transformer | No |
| ● light source | Yes |
| ● series resistor | No |
| insulation voltage rated value | 320 V |
| degree of pollution | 3 |
| type of voltage of the operating voltage | AC/DC |
| ● for actuation | AC/DC |
| surge voltage resistance rated value | 4 kV |
| consumed current maximum | 25 mA |
| protection class IP | - |
| ● of the enclosure | IP40 |
| ● of the terminal | IP20 |
| shock resistance | - |
| ● acc. to IEC 60068-2-27 | Sinusoidal half-wave 50g / 11 ms |
| vibration resistance | - |
| ● acc. to IEC 60068-2-6 | 10 ... 500 Hz: 5g |
| ● for railway applications acc. to DIN EN 61373 | Category 1, Class B |
| operating period typical | 100 000 h |
| reference code acc. to IEC 81346-2 | P |
| operating voltage 1 | - |
| ● at AC | - |
| — at 50 Hz rated value | 24 V |
| — at 60 Hz rated value | 24 V |
| ● at DC rated value | 24 V |
| relative positive tolerance of the operating voltage | 25 % |
| relative negative tolerance of the operating voltage | 30 % |
| inrush current maximum | 2 A |
| type of electrical connection | spring-loaded terminals |
| type of connectable conductor cross-sections | - |
| ● solid without core end processing | 2x (0.25 ... 1.5 mm²) |
| ● finely stranded with core end processing | 2x (0.25 ... 0.75 mm²) |
| ● finely stranded without core end processing | 2x (0.25 ... 1.5 mm²) |
| ● at AWG cables | 2x (24 ... 16) |
| type of light source | LED |
| color of the light source | white |
| light intensity | 900 ... 1 400 mcd |
| certificate of suitability | - |
| ● ATEX | No |
| ● IECEx | No |
| ambient temperature | - |
| ● during operation | -25 ... +70 °C |
| ● during storage | -40 ... +80 °C |
| environmental category during operation acc. to IEC 60721 | 3M6, 3S2, 3B2, 3C3, 3K6 (with relative air humidity of 10 ... 95 %, no condensation in operation permitted) |
| fastening method | - |
| ● of modules and accessories | Front plate mounting |
| last modified: | 10/6/2021 |
| Weight | 0.008 kg |
| Dimensions | 103.00 × 49.00 × 20.00 mm |
