Siemens 3TB3901-0XF0 AC Contactor 110V AC, 2.2kW, 1 NC, Size 0 Original Brand New

Overview

The Siemens 3TB3901-0XF0 Contactor is a high-quality, reliable electrical component designed for switching and controlling AC loads. This specific model operates with a 110V AC coil at a frequency of 50 Hz. It is rated for AC-3 applications, handling a current of 6 A at 400 V and a maximum power of 2.2 kW. Ideal for motor control, lighting, and other industrial applications, this contactor features a compact Size 0 frame.

Key Features & Benefit

• Efficient Performance: The 2.2 kW power rating and 6 A current capacity at 400 V ensure it can effectively handle a wide range of industrial and commercial loads.
• Reliable Auxiliary Contacts: Equipped with one normally closed (1 NC) auxiliary contact for integrated control and signaling within a circuit.
• Robust & Compact Design: The Size 0 frame makes it suitable for installations with limited space, without compromising on performance or durability.
• Secure Screw Connection: Provides a strong, reliable connection for wiring, ensuring secure and stable operation.
• Safety & Durability: Manufactured by Siemens, a leader in industrial automation, guaranteeing long-lasting performance and compliance with industry standards.

Function

The Siemens 3TB3901-0XF0 Contactor acts as an electrically controlled switch used for switching a power circuit. When the coil is energized by the 110V AC control voltage, it closes the main power contacts, allowing current to flow to the connected load (e.g., a motor). This function is critical for automating machinery and protecting circuits from overloads.

Technical Specification

• Product Number: 3TB3901-0XF0
• Product Type: Contactor
• Frequency: 50 Hz
• Coil Voltage: 110 V AC
• Rated Current (AC-3): 6 A @ 400 V
• Rated Power (AC-3): 2.2 kW
• Auxiliary Contacts: 1 NC (Normally Closed)
• Size: 0
• Connection Type: Screw Connection
