Siemens 5SJ4216-7HG41 Miniature Circuit Breaker 2-Pole, 16A, 240V, C-Trip, UL 489 Original Brand New
$93.49
High-performance, 2-pole miniature circuit breaker designed for branch circuit protection. Rated at 16A and 240V with a 14kA interrupting capacity, this C-trip characteristic breaker is fully compliant with UL 489 standards for industrial and commercial applications.
Availability: In stock
Overview
The Siemens 5SJ4216-7HG41 is part of the premium Sentron series, engineered for demanding electrical environments. With a mounting depth of 70 mm, this 2-pole miniature circuit breaker (MCB) provides robust protection against overloads and short circuits. It is specifically designed to meet UL 489 (Branch Circuit Protection), making it suitable for use in control panels and machinery destined for the North American market.
Key Benefit
-
Certified Safety: Fully compliant with UL 489, CSA C22.2, and IEC standards for global versatility.
-
High Breaking Capacity: Handles short-circuit currents up to 14kA at 240V.
-
Space-Efficient: Compact 70 mm design allows for streamlined DIN rail installation.
-
Reliable Performance: C-Trip characteristic is ideal for circuits with moderate inductive loads and high inrush currents.
Function & Features
-
2-Pole Configuration: Provides simultaneous switching for two-phase circuits.
-
Trip Curve C: Balanced protection for resistive and slightly inductive loads.
-
Easy Installation: Standard DIN rail mounting with clear status indicators.
-
Branch Circuit Rated: Approved for protection of the final circuit, unlike standard supplementary protectors.
Technical Specification
-
Product Number: 5SJ4216-7HG41
-
Brand: Siemens
-
Type: Miniature Circuit Breaker (MCB)
-
Poles: 2
-
Rated Voltage: 240 V
-
Rated Current: 16A
-
Tripping Curve: C
-
Breaking Capacity: 14kA
-
Depth (D): 70 mm
-
Standard: UL 489
Visit 5SJ4216-7HG41 for more detail info
For more our products visit turll
Download
| Weight | 0.328 kg |
|---|---|
| Dimensions | 40.00 × 114.00 × 84.00 mm |
| Brand | SIEMENS |
| product brand name | SENTRON |
| product designation | Miniature circuit breakers |
| design of the product | Miniature circuit-breaker 5SJ4 |
| number of poles | 2 |
| tripping characteristic class | C |
| mechanical service life (switching cycles) / typical | 10 000 |
| installation environment regarding EMC | Suitable for environment B (immunity to interference not applicable) |
| reference code / acc. to DIN 40719 extended according to IEC 204-2 / acc. to IEC 750 | F |
| overvoltage category | 3 |
| degree of pollution | 3 |
| type of voltage / of the operating voltage | AC/DC |
| insulation voltage (Ui) / at AC / rated value | 440 V |
| supply voltage / at AC / rated value | 400 V |
| operating voltage | – |
| ● at AC / acc. to UL 489 and CSA C22.2 No. 5-02 / maximum | 240 V |
| ● at DC / rated value / maximum | 60 V |
| ● at DC / single channel / acc. to UL 489 and CSA C22.2 No. 5-02 / maximum | 60 V |
| ● at DC / 2-channel / acc. to UL 489 and CSA C22.2 No. 5-02 / maximum | 125 V |
| protection class IP | IP20, with connected conductors, IP 40 in the handle range |
| switching capacity current | – |
| ● acc. to EN 60898 / rated value | 10 kA |
| ● acc. to IEC 60947-2 / rated value | 15 kA |
| power loss [W] / for rated value of the current / at AC / in hot operating state / per pole | 2.2 W |
| operational current | – |
| ● at 30 °C / rated value | 16 A |
| ● at 40 °C / rated value | 16 A |
| ● at 45 °C / rated value | 15.5 A |
| ● at 50 °C / rated value | 15.2 A |
| ● at 55 °C / rated value | 14.8 A |
| ● at 60 °C / rated value | 14.4 A |
| ● at AC / rated value | 16 A |
| type of voltage supply / at AC / acc. to UL 489 and CSA C22.2 No. 5-02 | 240 |
| suitability for operation | Mechanical engineering / industry |
| product component / neutral conductor switching | No |
| product feature / touch protection | Yes |
| product component | – |
| ● tunnel terminals top | No |
| ● tunnel terminals bottom | No |
| ● combined terminal top | Yes |
| ● combined terminal bottom | Yes |
| product feature | – |
| ● halogen-free | Yes |
| ● sealable | Yes |
| ● silicon-free | Yes |
| product extension / installable / supplementary devices | Yes |
| product function / note | Terminal tightening torque for Cu, 60/75°C; 3.5Nm/31lb.in |
| breaking capacity short-circuit current (Icn) / at AC / acc. to UL 1077 and CSA C22.2 No.235 | 14 kA |
| connectable conductor cross-section / finely stranded / with core end processing | – |
| tightening torque / with screw-type terminals / maximum | 3.5 N·m |
| position / of power supply cord | Any |
| installation depth | 70 mm |
| number of modular width units | 2 |
| fastening method | on standard mounting rail |
| mounting position | any |
| vibration resistance | 50 m/s² at 25 to 150Hz and 60m/s² at 35Hz (4sec) |
| ambient temperature / during operation | – |
| ambient temperature / during storage | – |
| ● minimum | -40 °C |
| ● maximum | 75 °C |
| reference code | – |
| ● acc. to DIN EN 61346-2 | F |
| ● acc. to IEC 81346-2 | F |
| Test Certificates | other |
| Special Test Certificate | Miscellaneous |
