Siemens 6AV2124-0GC01-0AX0 SIMATIC HMI TP700, Comfort Panel, 7" Touchscreen, PROFINET
Siemens 6AV2124-0GC01-0AX0 SIMATIC HMI TP700, Comfort Panel, 7" Touchscreen, PROFINET
Siemens 6AV2124-0GC01-0AX0 SIMATIC HMI TP700, Comfort Panel, 7" Touchscreen, PROFINET
Siemens 6AV2124-0GC01-0AX0 SIMATIC HMI TP700, Comfort Panel, 7" Touchscreen, PROFINET
Siemens 6AV2124-0GC01-0AX0 SIMATIC HMI TP700, Comfort Panel, 7" Touchscreen, PROFINET

SIEMENS

Siemens 6AV2124-0GC01-0AX0 SIMATIC HMI TP700, Comfort Panel, 7″ Touchscreen, PROFINET Original Brand New

Model / SKU6AV2124-0GC01-0AX0

SIMATIC HMI TP700 Comfort Panel with 7″ widescreen TFT display, touch operation, PROFINET & MPI/PROFIBUS interfaces, 16 million colors, 12 MB memory, Windows CE 6.0, configurable via WinCC Comfort V11.

Original price was: $1,589.96.Current price is: $785.37.
In stockShips in 1–3 business days
  • ConditionOriginal Brand New
  • Warranty12 months
Request bulk quoteAsk on WhatsApp
  • Genuine Products
  • Up to 1-Year Warranty
  • Global Shipping
  • Secure Payment
  • PI / Bank Transfer Available
  • Bulk Quote Support

Description

Overview

The Siemens 6AV2124-0GC01-0AX0 SIMATIC HMI TP700 Comfort Panel is a high-performance human-machine interface designed for industrial automation applications. With a 7-inch widescreen TFT display offering 16 million colors, intuitive touch operation, and robust connectivity via PROFINET and MPI/PROFIBUS DP, this HMI panel ensures seamless operation in complex industrial environments. The device runs on Windows CE 6.0 and can be easily configured using WinCC Comfort V11.

Key Features & Function

  • High-Resolution Touch Display: 7” widescreen TFT with 16 million colors for clear visualization.

  • Flexible Connectivity: Supports PROFINET, MPI, and PROFIBUS DP interfaces for versatile communication.

  • Robust Performance: 12 MB configuration memory ensures smooth operation of complex automation projects.

  • Advanced Operating System: Windows CE 6.0 provides stable and reliable performance.

  • Easy Configuration: Fully configurable via WinCC Comfort V11 software.

  • Industrial Reliability: Designed to operate in demanding industrial environments.

Benefit

  • Superior Visualization: The 7-inch widescreen display offers 40% more viewing area than conventional panels, providing more space for detailed graphical interfaces, trend curves, and plant documentation.

  • Maximum Connectivity: Integrated PROFINET/MPI/PROFIBUS DP interfaces ensure flexible integration into all SIMATIC automation systems (S7-1200, S7-1500, S7-300, etc.) and comprehensive network options.

  • High Performance: Powered by a robust X86 processor and equipped with 12 MB of user memory, the panel delivers fast screen changes and efficient processing of archives and complex applications.

  • Energy Efficiency (PROFIenergy): Can be centrally shut down via PROFIenergy, significantly reducing power consumption during non-production times.

  • Enhanced Security: Features high-level user administration and maximum data security through innovative backup and restore functions.

Application

The SIMATIC HMI TP700 Comfort is the ideal solution for high-end visualization tasks across various industries:

  • Manufacturing Automation

  • Process Control and Monitoring

  • Machine Building (OEM)

  • Water/Wastewater Treatment Plants

  • Building Automation Systems

Download

Datasheet in PDF

Visit 6AV2124-0GC01-0AX0 for more detail info

For more our products visit turll

Specifications

SKU / Model6AV2124-0GC01-0AX0
BrandSIEMENS
Product type designationTP700 Comfort
Design of displayTFT
Screen diagonal7 in
Display width152.4 mm
Display height91.4 mm
Number of colors16 777 216
● Horizontal image resolution800 pixel
● Vertical image resolution480 pixel
● MTBF backlighting (at 25 °C)80 000 h
● Backlight dimmableYes; 0-100 %
● Function keys-
— Number of function keys0
— Number of function keys with LEDs0
● Keys with LEDNo
● System keysNo
● Numeric keyboardYes; Onscreen keyboard
● alphanumeric keyboardYes; Onscreen keyboard
● Design as touch screenYes; Analog-resistive
● DP direct LEDs (LEDs as S7 output I/O)-
● Direct keys (keys as S7 input I/O)-
— F1...Fx0
● Direct keys (touch buttons as S7 input I/O)32
Mounting positionvertical
Wall mounting/direct mountingNo
Mounting in portrait format possibleYes
Mounting in landscape format possibleYes
maximum permissible angle of inclination without external ventilation35°
Type of supply voltageDC
Rated value (DC)24 V
permissible range, lower limit (DC)19.2 V
permissible range, upper limit (DC)28.8 V
Current consumption (rated value)0.5 A
Starting current inrush I²t0.5 A²·s
Active power input, typ.12 W
Processor typeX86
FlashYes
RAMYes
Memory available for user data12 Mbyte
Info LEDNo
Power LEDNo
Error LEDNo
Acoustics-
● BuzzerNo
● SpeakerYes
● Hardware clock (real-time)Yes
● Software clockYes
● retentiveYes; Back-up duration typically 6 weeks
● synchronizableYes
Number of industrial Ethernet interfaces1; 2 ports (switch)
Number of RS 485 interfaces1; RS 422 / 485 combined
Number of RS 422 interfaces0; together with RS 485
Number of RS 232 interfaces0
Number of USB interfaces2; USB 2.0
● USB Mini B1; 5-pole
Number of 20 mA interfaces (TTY)0
Number of parallel interfaces0
Number of other interfaces0
Number of SD card slots2
With software interfacesNo
● Industrial Ethernet status LED2
● Number of ports of the integrated switch2
PROFINETYes
Supports protocol for PROFINET IOYes
IRTYes; As of WinCC V12
PROFIBUSYes
EtherNet/IPYes
MPIYes
● TCP/IPYes
● DHCPYes
● SNMPYes
● DCPYes
● LLDPYes
● HTTPYes
● HTTPSYes
● HTMLYes
● XMLYes
● CSSYes
● Active XYes
● JavaScriptYes
● Java VMNo
— MRPYes; As of WinCC V12
● CANNo
● MODBUSYes
● Diagnostic information readableYes; S7 controller
● Limit class A, for use in industrial areasYes
● Limit class B, for use in residential areasNo
IP (at the front)IP65
IP (rear)IP20
NEMA (front)-
● Enclosure Type 4 at the frontYes
● Enclosure Type 4x at the frontYes
CE markYes
cULusYes
RCM (formerly C-TICK)Yes
KC approvalYes
● ATEX Zone 2Yes
● ATEX Zone 22Yes
● IECEx Zone 2Yes
● IECEx Zone 22Yes
● cULus Class I Zone 1No
● cULus Class I Zone 2, Division 2Yes
● FM Class I Division 2Yes
● Germanischer Lloyd (GL)Yes
● American Bureau of Shipping (ABS)Yes
● Bureau Veritas (BV)Yes
● Det Norske Veritas (DNV)Yes
● Lloyds Register of Shipping (LRS)Yes
● Nippon Kaiji Kyokai (Class NK)Yes
● Polski Rejestr Statkow (PRS)No
— For vertical installation, min.0 °C
— For vertical installation, max.40 °C
— At maximum tilt angle, min.35 °C
● min.-20 °C
● max.60 °C
● Operation, max.90 %; no condensation
proprietaryNo
● Windows CEYes
Message indicatorYes
Alarm system (incl. buffer and acknowledgment)Yes
Process value display (output)Yes
Process value default (input) possibleYes
Recipe managementYes
● STEP 7 Basic (TIA Portal)No
● STEP 7 Professional (TIA Portal)No
● WinCC flexible CompactNo
● WinCC flexible StandardNo
● WinCC flexible AdvancedNo
● WinCC Basic (TIA Portal)No
● WinCC Comfort (TIA Portal)Yes; from V11
● WinCC Advanced (TIA Portal)Yes; from V11
● WinCC Professional (TIA Portal)Yes; from V11
● Number of online/runtime languages32
● Languages per project32
LibrariesYes
Applications/options-
● Web browserYes
● Pocket WordYes
● Pocket ExcelYes
● PDF ViewerYes
● SIMATIC WinCC Sm@rtServerYes
● SIMATIC WinCC AuditYes
Number of Visual Basic ScriptsYes
Task planner-
● time-controlledYes
● task-controlledYes
Help system-
● Number of characters per info text70
● Number of alarm classes32
● Bit messagesYes
— Number of bit messages4 000
● Analog messagesYes
— Number of analog messages200
● S7 alarm number procedureYes
● System messages HMIYes
● System event, more (SIMATIC S7, SINUMERIK, SIMOTION, ... )Yes
● Number of characters per message80
● Number of process values per message8
● Acknowledgment groupsYes
● Message indicatorYes
● Message buffer-
— Number of entries1 024
— Circulating bufferYes
— retentiveYes
— maintenance-freeYes
● Number of recipes300
● Data records per recipe500
● Entries per data record1 000
● Size of internal recipe memory2 Mbyte
● Recipe memory expandableYes
● Number of variables per device2 048
● Number of variables per screen400
● Limit valuesYes
● MultiplexingYes
● StructuresYes
● ArraysYes
● Number of configurable images500
● Permanent window/defaultYes
● Global imageYes
● Pop-up imagesYes
● Slide-in imagesYes
● Image selection by PLCYes
● Image number in the PLCYes
● Number of objects per image400
● Text fieldsYes
● I/O fieldsYes
● Graphic I/O fields (graphics list)Yes
● Symbolic I/O fields (text list)Yes
● SwitchesYes
● ButtonsYes
● Graphic displayYes
● IconsYes
● Geometric objectsYes
● Number of complex objects per screen20
● Alarm viewYes
● Trend viewYes
● User viewYes
● Status/controlYes
● Sm@rtClient viewYes
● Recipe viewYes
● f(x) trend viewYes
● System diagnostics viewYes
● Media PlayerYes
● HTML browserYes
● PDF displayYes
● IP camera displayYes
● Bar graphsYes
● SlidersYes
● Pointer instrumentsYes
● Analog/digital clockYes
Product ConditionBrand New, New - Backlog, New - No Original Box, New - Original Box Opened, Used - Average, Used - Below Average, Used - Excellent, Used - Fairly Good, Used - Good, Used - Poor, Used - Very Good
Weight1.463 kg
Dimensions17.20 × 27.30 × 8.60 mm
