Siemens 6AV6647-0AJ11-3AX0 SIMATIC HMI KP400 Basic Color PN, 4″ Touch Panel Original Brand New

Model / SKU6AV6647-0AJ11-3AX0

High-performance SIMATIC HMI KP400 Basic Color PN panel. Featuring a 4-inch widescreen TFT display with 256 colors and tactile key operation, it offers seamless integration via a PROFINET interface for entry-level HMI applications.

$421.30
In stockShips in 1–3 business days
  • ConditionOriginal Brand New
  • Warranty12 months
Request bulk quoteAsk on WhatsApp
  • Genuine Products
  • Up to 1-Year Warranty
  • Global Shipping
  • Secure Payment
  • PI / Bank Transfer Available
  • Bulk Quote Support

Description

Overview

The Siemens 6AV6647-0AJ11-3AX0 is a high-performance SIMATIC HMI KP400 Basic Color PN panel designed for efficient industrial automation. Featuring a 4-inch widescreen TFT display with 256 colors, this panel enables intuitive key operation and streamlined control of machinery and processes.

Fully compatible with PROFINET, the KP400 ensures fast and reliable communication within your industrial network. Configuration is simple using WinCC Basic V11 SP2 or STEP 7 Basic V11 SP2, making it an ideal solution for small to medium-sized automation projects. The panel also includes open-source software, provided free of charge on the enclosed CD.

Key Features & Function

  • 4" widescreen TFT color display with 256 colors

  • Key-operated basic panel for easy navigation

  • High-speed PROFINET interface for reliable connectivity

  • Configurable via WinCC Basic V11 SP2 / STEP 7 Basic V11 SP2

  • Supports open-source software (included on CD)

  • Compact design suitable for space-constrained installations

Benefit

  • Cost-Efficient Visualization: High-resolution widescreen display at an entry-level price point.

  • Tactile Precision: Key-operated interface designed for environments where glove-use or tactile feedback is required.

  • Seamless Integration: Fully compatible with TIA Portal (WinCC Basic V11 SP2 or higher).

  • Rugged Design: Built for industrial environments with the reliability synonymous with the Siemens SIMATIC range.

Download

Datasheet in PDF

Visit 6AV6647-0AJ11-3AX0 for more detail info

For more our products visit turll



Specifications

SKU / Model6AV6647-0AJ11-3AX0
BrandSIEMENS
Product type designationKP400 Basic color PN
Design of displayTFT
Screen diagonal4.3 in
Display width95 mm
Display height53.8 mm
Number of colors256
● Horizontal image resolution480 pixel
● Vertical image resolution272 pixel
● MTBF backlighting (at 25 °C)50 000 h
● Backlight dimmableNo
● Function keys-
— Number of function keys8
— Number of function keys with LEDs0
● Keys with LEDNo
● System keysYes
● Numeric keyboardYes; Keyboard
● alphanumeric keyboardYes; similar to mobile phone
● Design as touch screenNo; without
Mounting positionvertical
Wall mounting/direct mountingNo
Mounting in portrait format possibleNo
Mounting in landscape format possibleYes
maximum permissible angle of inclination without external ventilation35°
Type of supply voltageDC
Rated value (DC)24 V
permissible range, lower limit (DC)19.2 V
permissible range, upper limit (DC)28.8 V
Current consumption (rated value)0.1 A
Starting current inrush I²t0.5 A²·s
Active power input, typ.2 W
Processor typeRISC 32 bit
FlashYes
RAMYes
Memory available for user data1 Mbyte
Acoustics-
● BuzzerNo
● SpeakerNo
● Hardware clock (real-time)No
● Software clockYes
● retentiveNo
● synchronizableYes
Number of industrial Ethernet interfaces1
Number of RS 485 interfaces0
Number of RS 422 interfaces0
Number of RS 232 interfaces0
Number of USB interfaces0
Number of 20 mA interfaces (TTY)0
Number of parallel interfaces0
Number of other interfaces0
Number of SD card slots0
With software interfacesNo
● Industrial Ethernet status LED2
PROFINETYes
Supports protocol for PROFINET IONo
IRTNo
PROFIBUSNo
EtherNet/IPYes
MPINo
● TCP/IPYes
● DHCPYes
● SNMPYes
● DCPYes
● LLDPYes
● HTTPNo
● HTMLNo
● CANNo
● MODBUSYes; Modicon (MODBUS TCP/IP)
● Limit class A, for use in industrial areasYes
● Limit class B, for use in residential areasNo
IP (at the front)IP65
IP (rear)IP20
NEMA (front)-
● Enclosure Type 4 at the frontYes
● Enclosure Type 4x at the frontYes
CE markYes
cULusYes
RCM (formerly C-TICK)Yes
KC approvalYes
● ATEX Zone 2No
● ATEX Zone 22No
● cULus Class I Zone 1No
● cULus Class I Zone 2, Division 2No
● FM Class I Division 2No
● Germanischer Lloyd (GL)No
● American Bureau of Shipping (ABS)No
● Bureau Veritas (BV)No
● Det Norske Veritas (DNV)No
● Lloyds Register of Shipping (LRS)No
● Nippon Kaiji Kyokai (Class NK)No
● Polski Rejestr Statkow (PRS)No
— For vertical installation, min.0 °C
— For vertical installation, max.50 °C
— At maximum tilt angle, min.40 °C
● min.-20 °C
● max.60 °C
● Operation, max.90 %; no condensation
proprietaryYes
● Windows CENo
Message indicatorYes
Alarm system (incl. buffer and acknowledgment)Yes
Process value display (output)Yes
Process value default (input) possibleYes
Recipe managementYes
● STEP 7 Basic (TIA Portal)Yes; via integrated WinCC Basic (TIA Portal)
● STEP 7 Professional (TIA Portal)Yes; via integrated WinCC Basic (TIA Portal)
● WinCC flexible CompactNo
● WinCC flexible StandardNo
● WinCC flexible AdvancedNo
● WinCC Basic (TIA Portal)Yes
● WinCC Comfort (TIA Portal)Yes
● WinCC Advanced (TIA Portal)Yes
● WinCC Professional (TIA Portal)Yes
● Number of online/runtime languages5
● Languages per project32
LibrariesYes
Task planner-
● time-controlledNo
● task-controlledYes
Help systemYes
● Number of characters per info text320
● Number of alarm classes32
● Bit messages-
— Number of bit messages200
● Analog messages-
— Number of analog messages15
● System messages HMIYes
● Number of characters per message80
● Number of process values per message8
● Message indicatorYes
● Message buffer-
— Number of entries256
— Circulating bufferYes
— retentiveYes
— maintenance-freeYes
● Number of recipes5
● Data records per recipe20
● Entries per data record20
● Size of internal recipe memory40 kbyte
● Recipe memory expandableNo
● Number of variables per device500
● Number of variables per screen30
● Limit valuesYes
● MultiplexingYes
● StructuresNo
● ArraysYes
● Number of configurable images50
● Permanent window/defaultYes; No permanent window can be configured
● Global imageYes
● Image selection by PLCYes
● Image number in the PLCYes
● Number of objects per image30
● Text fieldsYes
● I/O fieldsYes
● Graphic I/O fields (graphics list)Yes
● Symbolic I/O fields (text list)Yes
● SwitchesYes
● ButtonsYes
● Graphic displayYes
● IconsYes; Predefined screen objects
● Geometric objectsYes
● Number of complex objects per screen5
● Alarm viewYes
● Trend viewYes
● User viewYes
● Status/controlNo
● Sm@rtClient viewNo
● Recipe viewYes
● f(x) trend viewNo
● System diagnostics viewNo
● Media PlayerNo
● Bar graphsYes
● SlidersNo
● Pointer instrumentsNo
● Analog/digital clockNo
● Number of text lists per project150
● Number of entries per text list30
● Number of graphics lists per project100
● Number of entries per graphics list30
● Number of archives per device0
● Number of user groups50
● Number of user rights32
● Number of users50
● Password export/importNo
● SIMATIC LogonNo
● Keyboard fonts-
— US EnglishYes
● MPI/PROFIBUS DPNo
● USBNo
● EthernetYes
● using external storage mediumNo
● S7-1200Yes
● S7-1500Yes
● S7-200Yes
● S7-300/400Yes
● LOGO!Yes
● WinACNo
● SINUMERIKNo
● SIMOTIONNo
● Allen Bradley (EtherNet/IP)Yes
● Allen Bradley (DF1)No
● Mitsubishi (MC TCP/IP)Yes
● Mitsubishi (FX)No
● OMRON (FINS TCP)No
● OMRON (LINK/Multilink)No
● Modicon (Modbus TCP/IP)Yes
● Modicon (Modbus)No
● Backup/Restore manuallyYes
● Backup/Restore automaticallyNo
● SimulationYes
● Device switchoverYes
PrinterNo
SIMATIC HMI MM memory card: Multi Media CardNo
SIMATIC HMI SD memory card: Secure Digital memory cardNo
USB memoryNo
Enclosure material (front)-
● PlasticYes
● AluminumNo
● Stainless steelNo
Width of the housing front162 mm
Height of housing front189 mm
Mounting cutout, width135 mm
Mounting cutout, height171 mm
Overall depth33 mm
Weight (without packaging)0.51 kg
Weight (with packaging)0.66 kg
Weight0.633 kg
Dimensions17.40 × 24.80 × 4.80 mm
