6ES7223-1PM22-0XA8

Description

Overview

The 6ES7223-1PM22-0XA8 EM 223 expansion module is engineered for industrial automation tasks requiring significant I/O expansion. As part of the SIMATIC S7-200 CN range, it is specifically optimized for use with S7-22X CPUs. This module allows for flexible integration of both sink and source digital inputs alongside reliable relay outputs capable of handling up to 2 A per channel.

Key Benefit

• High I/O Density: Consolidate your automation footprint with 64 total I/O points in a single expansion module.

• Versatile Connectivity: Supports both sink and source configurations for 24V DC digital inputs.

• High-Current Relay Outputs: The 32 relay outputs support up to 2 A per channel, ideal for driving actuators and heavy-duty industrial components.

• Seamless Integration: Designed for “plug-and-play” compatibility with existing S7-22X CPU setups.

• Cost-Effective Scalability: Expand your system’s logic capacity without replacing the primary controller.

Function

• Processes 32 digital input signals (24 V DC)

• Controls 32 relay digital output channels

• Supports 2 A switching capacity per output channel

• Seamlessly integrates with S7-22X CPU controllers

• Enables efficient control of sensors, actuators, and relays

Technical Specification

• Model Number: 6ES7223-1PM22-0XA8

• Product Series: SIMATIC S7-200 CN

• Module Type: EM 223 Digital I/O

• Digital Inputs: 32 × 24 V DC (sink/source)

• Digital Outputs: 32 × Relay

• Output Current: 2 A per channel

• Compatible CPU: S7-22X only

• Certification: CE approved
