Siemens 6SL3210-1PE28-8AL0 | SINAMICS G120 Power Module PM240-2 with Braking Chopper & CL. A Filter Original Brand New

Overview

The Siemens 6SL3210-1PE28-8AL0 SINAMICS G120 Power Module PM240-2 is a high-performance drive solution designed for demanding industrial applications. With a built-in Class A filter and integrated braking chopper, this module ensures stable and efficient motor operation. Designed for both high and low overload capacities, it provides flexibility and reliability for varying operational demands.

Key Features & Function

• Built-in Class A Filter: Reduces harmonic distortion and enhances power quality.

• Integrated Braking Chopper: Enables rapid energy dissipation during deceleration.

• Wide Input Range: Operates at 3AC380-480V ±10/-20%, 47-63Hz.

• High Overload Capacity (HO): 37kW for 200% 3s, 150% 57s, 100% 240s at -20°C to +50°C.

• Low Overload Capacity (LO): 45kW for 150% 3s, 110% 57s, 100% 240s at -20°C to +40°C.

• Compact Design: Dimensions 551 x 275 x 237 mm (H x W x D), IP20 protection.

• CU Approved: Compatible with firmware version V4.7 HF8, without the need for an external control unit or panel.

Benefit

• Reliable Industrial Performance: Ensures stable operation under high or low overload conditions.

• Energy Efficient: Braking chopper recycles energy effectively, reducing power consumption.

• Space-Saving Design: Compact footprint for easier installation in existing setups.

• Compliance & Safety: FSE protection and CU-approved firmware ensure industrial-grade safety.

Visit 6SL3210-1PE28-8AL0 for more detail info

For more our products visit turll

Download

Datasheet in PDF
