1FK2104-5AF01-1MA0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New
$796.16
SIEMENS SIMOTICS S-1FK2 High Dynamic servo motor, 2.4 Nm torque, 0.75 kW at 3000 rpm, multiturn encoder AM22DQC, IP65 protection, OCC interface.
1FK2104-5AF01-1MA0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New
The SIEMENS 1FK2104-5AF01-1MA0 SIMOTICS S-1FK2 High Dynamic servo motor is a powerful and compact solution designed for high-precision motion control in demanding industrial applications. Delivering a rated torque of 2.4 Nm and a power rating of 0.75 kW at 3000 rpm (380–480 V), or 0.375 kW at 1500 rpm (200–240 V), this synchronous motor ensures exceptional flexibility and efficiency across multiple voltage ranges. Its robust IP65 protection rating, 19×40 mm shaft with feather key, and high-resolution absolute multiturn encoder (22-bit + 12-bit AM22DQC) provide long-term reliability and excellent positioning accuracy.
Equipped with a rotatable M17 connector and OCC interface, the motor offers straightforward integration and optimized connectivity within automation systems. This makes it especially well-suited for use in robotics, packaging machines, handling equipment, and other applications requiring consistent dynamic performance.
Overview
The SIMOTICS S-1FK2 series stands out for its compact design, high power density, overload capacity, and seamless compatibility with SINAMICS S210 drive systems. These motors provide an ideal balance of precision, performance, and simplified configuration, allowing engineers to easily select and deploy them across a broad range of motion control tasks.
For enhanced versatility, the 1FT2 motor range expands on the 1FK2 portfolio by offering finer speed gradations, additional torque levels, and a wider variety of configurations. This ensures even the most complex or demanding drive technology challenges can be solved with accuracy and efficiency.
Whether required for high-speed applications with minimal inertia or for stable control with larger moving masses, the 1FK2 series delivers proven SIEMENS engineering quality, supporting productivity and innovation in modern automation environments.
Download
Product Code: 1FK2104-5AF01-1MA0
More Siemens products at Turll.com
| Weight | 2.85 kg |
|---|---|
| Dimensions | 452 × 250 × 267 mm |
