SIEMENS SIMOTICS S-1FK2 HD servo motor with 2.4 Nm torque, 0.75 kW at 3000 rpm, IP64 protection, encoder AS22DQC, and DRIVE-CLiQ connectivity.
Backorder available · Factory lead time 2–3 weeks.
The SIEMENS 1FK2104-5AF10-1SB0 SIMOTICS S-1FK2 High Dynamic servo motor is a precision-engineered synchronous motor designed for modern industrial automation. Delivering a rated torque of 2.4 Nm and a power output of 0.75 kW at 3000 rpm with 380–480 V supply, or 0.375 kW at 1500 rpm with 200–240 V supply, this motor offers consistent performance across multiple voltage ranges. Featuring an integrated holding brake, IP64 degree of protection, and a robust 19x40 mm shaft with a feather key, it is built to withstand rigorous operational demands in challenging environments.
Equipped with a single-turn 22-bit absolute encoder (AS22DQC) and a DRIVE-CLiQ plug (M17), the motor ensures precise feedback and seamless integration with SINAMICS servo drive systems. Its compact size, combined with high power density and overload capacity, makes it an excellent choice for robotics, packaging machinery, CNC systems, and a variety of other automation applications requiring both reliability and accuracy.
The SIMOTICS S-1FK2 series represents SIEMENS’ commitment to efficient and dynamic drive solutions. With simplified selection due to a streamlined portfolio, these motors form the foundation of the SINAMICS S210 drive system. They provide superior motion control in both highly dynamic applications with low inertia loads and medium-inertia systems where stability is essential.
Extending this portfolio, the 1FT2 motors offer finer speed gradations, higher torque levels, and additional variations, ensuring adaptability to even more demanding requirements. Together, the SIMOTICS motor families empower industries with scalable and precise solutions for advanced motion control.
Product Code: 1FK2104-5AF10-1SB0
More Siemens products at Turll.com
| SKU / Model | 1FK2104-5AF10-1SB0 |
|---|---|
| Weight | 3.7 kg |
| Dimensions | 452 × 250 × 267 mm |
