1FK2104-5AF11-1MB0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New

1FK2104-5AF11-1MB0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New

The SIEMENS 1FK2104-5AF11-1MB0 SIMOTICS S-1FK2 High Dynamic servo motor is a premium synchronous motor engineered for accuracy, efficiency, and reliability in modern automation systems. With a torque of 2.4 Nm and a rated power output of 0.75 kW at 3000 rpm (380–480 V), or 0.375 kW at 1500 rpm (200–240 V), this motor delivers exceptional flexibility across different voltage ranges. Its rugged design, complete with IP65 protection, integrated holding brake, and a 19x40 mm shaft with feather key, ensures durability even in challenging environments.

Equipped with an advanced 22-bit absolute encoder combined with a 12-bit multiturn encoder (AM22DQC), the motor guarantees precise motion feedback and positioning accuracy. The DRIVE-CLiQ M17 interface simplifies integration with SINAMICS drive systems, while the compact frame allows installation in space-limited control cabinets or high-performance machinery. This makes the unit suitable for robotics, packaging, printing, and motion-intensive machine applications where repeatable accuracy is critical.

Overview

The SIMOTICS S-1FK2 family combines compact dimensions with outstanding power density, enabling stable performance and overload capability. Designed as the core motor series for the SINAMICS S210 servo drive system, it balances ease of selection with technical versatility. The motors provide scalable options for users who require either highly dynamic response in low-inertia setups or precise stability for heavier load handling.

For applications requiring expanded capability, the 1FT2 motors extend the 1FK2 portfolio by offering additional torque levels, speed options, and mechanical variations. Together, both series support a wide spectrum of automation needs, from basic control systems to advanced high-speed industrial solutions.

Download

Data Sheet (PDF)

Product Code: 1FK2104-5AF11-1MB0
