1FK2104-5AK01-1SB0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New
$625.62
SIEMENS SIMOTICS S-1FK2 High Dynamic servo motor, 2.4 Nm torque, 1.07 kW power, IP65 protection, encoder AS22DQC, DRIVE-CLiQ interface.
1FK2104-5AK01-1SB0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New
The SIEMENS 1FK2104-5AK01-1SB0 SIMOTICS S-1FK2 High Dynamic servo motor delivers exceptional performance and reliability for a wide range of industrial automation applications. Offering a rated torque of 2.4 Nm and power outputs of 1.07 kW at 6000 rpm (380–480 V) and 0.75 kW at 3000 rpm (200–240 V), this motor ensures precise control under varied operating conditions. With an IP65 protection rating, a robust shaft of 19×40 mm with feather key, and an integrated single-turn 22-bit absolute encoder (AS22DQC), the unit provides durability, accuracy, and seamless feedback for advanced drive systems.
Equipped with DRIVE-CLiQ M17 interface and compatible power connectors, the motor integrates smoothly with SINAMICS S210 servo drive systems. Its high power density and compact construction make it ideal for applications requiring dynamic response with low inertia as well as medium-to-high inertia systems that demand stable and precise motion control. This makes the 1FK2 motor suitable for robotics, packaging machinery, CNC equipment, and other automated industrial systems.
Overview
The SIMOTICS S-1FK2 series is a line of compact synchronous motors engineered for high dynamic response, overload capability, and reliable operation. The 1FK2 range offers a streamlined selection of variants, simplifying configuration and deployment. For more complex requirements, the 1FT2 family extends the portfolio with additional torque levels, speed gradations, and optional features, allowing precise matching to application-specific demands.
These motors excel in environments that require both rapid acceleration and stable positioning. Their combination of compact size, robust construction, and high-performance electronics ensures optimal results even in demanding industrial contexts.
Download
Product Code: 1FK2104-5AK01-1SB0
More Siemens products at Turll.com
| Weight | 2.85 kg |
|---|---|
| Dimensions | 452 × 250 × 267 mm |
