1FK2104-5AK10-0MB0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New
$885.24
SIEMENS SIMOTICS S-1FK2 High Dynamic servo motor with 2.4 Nm torque, 1.07 kW power, IP64 protection, AM22DQC encoder, and DRIVE-CLiQ interface.
1FK2104-5AK10-0MB0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New
The SIEMENS 1FK2104-5AK10-0MB0 SIMOTICS S-1FK2 High Dynamic servo motor is engineered for precision, high performance, and reliable operation in industrial automation environments. Offering a rated torque of 2.4 Nm, this motor provides 1.07 kW at 6000 rpm (380–480 V) and 0.75 kW at 3000 rpm (200–240 V). With an integrated holding brake and IP64 protection, it is designed for demanding conditions. The cylindrical shaft (19×40 mm) with a feather key ensures secure mechanical coupling, while the 22-bit + 12-bit multiturn absolute encoder (AM22DQC) provides precise feedback for accurate motion control.
Equipped with a DRIVE-CLiQ M17 plug and matching power connector, the unit offers seamless integration with SINAMICS S210 servo drive systems. Its compact, high-power design makes it ideal for applications in robotics, packaging, machine tools, and other automation systems requiring both high dynamic response and stable control. The combination of low inertia and high power density enables precise movement for low and medium mass loads alike.
Overview
The SIMOTICS S-1FK2 family delivers highly dynamic performance, robustness, and overload capability. It provides a simplified selection with limited variants, while maintaining the flexibility needed for various industrial requirements. The 1FK2 series serves as the core for SINAMICS S210 systems, offering efficient and reliable operation. For more complex requirements, the 1FT2 motors provide additional torque levels, finer speed gradations, and extended options, allowing customization for challenging applications in difficult environments.
Design
Compact and high-precision, the motor features a cylindrical shaft, integrated encoder, and reliable DRIVE-CLiQ connectivity. The motor’s construction ensures low-maintenance operation, smooth motion, and long service life. It is optimized for integration into medium- and high-inertia systems, providing both dynamic performance and stable, precise control.
Download
Product Code: 1FK2104-5AK10-0MB0
More Siemens products at Turll.com
| Weight | 3.7 kg |
|---|---|
| Dimensions | 452 × 250 × 267 mm |
