1FK2104-6AF10-0MA0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New

1FK2104-6AF10-0MA0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New

The SIEMENS 1FK2104-6AF10-0MA0 SIMOTICS S-1FK2 High Dynamic servo motor is a compact, high-performance synchronous motor designed for advanced industrial automation. Delivering a rated torque of 3.2 Nm with a power rating of 1 kW at 3000 rpm (380–480 V) or 0.5 kW at 1500 rpm (200–240 V), this motor provides versatile performance across different voltage ranges. With IP64 protection, a robust cylindrical shaft (19x40 mm), and an integrated holding brake, it offers reliable operation even under demanding conditions.

The motor features a high-resolution 22-bit absolute encoder combined with a 12-bit multiturn encoder (AM22DQC), ensuring precise positioning and feedback accuracy. Equipped with an OCC interface and rotatable M17 plug connectors, the design supports efficient installation and integration into complex systems. This makes the motor particularly well-suited for robotics, packaging machinery, and motion control tasks that demand speed, stability, and precision.

Overview

The SIMOTICS S-1FK2 motor series is engineered to address the core requirements of servo drive technology. With compact construction, high overload capability, and excellent power density, the 1FK2 family forms the foundation of the SINAMICS S210 servo drive system. Its simplified portfolio ensures ease of selection while maintaining flexibility for various automation scenarios.

For more specialized applications, the SIMOTICS 1FT2 motors extend the range with additional torque levels, refined speed options, and enhanced configuration possibilities. This combination allows industries to handle both standard and highly demanding tasks effectively, ensuring long-term performance in diverse environments.

Download

Data Sheet (PDF)

Product Code: 1FK2104-6AF10-0MA0
