1FK2104-6AF10-1MA0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New
$919.24
SIEMENS SIMOTICS S-1FK2 servo motor with 3.2 Nm torque, 1 kW output, IP64 protection, multiturn encoder AM22DQC, OCC interface, and rotatable M17 plug.
1FK2104-6AF10-1MA0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New
The SIEMENS 1FK2104-6AF10-1MA0 SIMOTICS S-1FK2 High Dynamic servo motor is a robust and compact synchronous motor designed to deliver precision, reliability, and high performance in demanding automation environments. With a rated torque of 3.2 Nm and power ratings of 1 kW at 3000 rpm (380–480 V) or 0.5 kW at 1500 rpm (200–240 V), this motor provides excellent flexibility across different operating voltages. The integrated holding brake, IP64 protection rating, and shaft design of D19x40 mm with a feather key ensure both durability and adaptability in diverse industrial applications.
Equipped with a high-resolution absolute encoder (AM22DQC, 22-bit + 12-bit multiturn) and an OCC interface with rotatable M17 plug, the motor guarantees precise motion feedback and straightforward connectivity. Its high power density, compact design, and dynamic performance make it an optimal choice for machine tools, packaging systems, robotics, and other automation technologies requiring accuracy and consistency.
Overview
The SIMOTICS S-1FK2 series is well known for combining compact construction with high overload capacity and dynamic response. The 1FK2 family forms the backbone of the SINAMICS S210 servo drive system and is designed to meet the essential challenges of servo drive technology in modern industrial automation. For users requiring more finely graded performance levels, the 1FT2 motor range extends this portfolio with additional torque variations, speed options, and configuration choices.
With SIMOTICS S-1FK2 High Dynamic motors, users gain superior performance for applications requiring low inertia and rapid response. The SIMOTICS Compact variants ensure stable, precise operation in systems with medium to high inertial loads. Together, these designs deliver scalable and reliable solutions that help industries meet complex motion control requirements effectively.
Download
Product Code: 1FK2104-6AF10-1MA0
More Siemens products at Turll.com
| Weight | 4.25 kg |
|---|---|
| Dimensions | 452 × 250 × 267 mm |
