1FK2105-6AF10-1SA0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New

1FK2105-6AF10-1SA0 SIEMENS Exclusive SIMOTICS S-1FK2 HD Servo Motor Original Brand New

The SIEMENS 1FK2105-6AF10-1SA0 SIMOTICS S-1FK2 servo motor is a high-performance synchronous motor designed to provide excellent efficiency, precision, and flexibility for industrial automation. Delivering a rated torque of 8 Nm and power output of 2.1 kW at 3000 rpm (380–480 V) or 1.26 kW at 1500 rpm (200–240 V), this motor is suitable for a wide range of demanding applications. It comes equipped with a reliable holding brake, IP64 protection, and a 19x40 mm shaft with a feather key, ensuring robust performance even under challenging operating conditions.

The integrated 22-bit single-turn absolute encoder (AS22DQC) provides accurate position feedback for smooth motion control, while the OCC interface with a rotatable M17 connector allows easy integration into drive systems. Built to complement the SINAMICS S210 servo drive family, the motor provides the dynamic response and overload capacity needed for applications such as robotics, machine tools, packaging, and advanced motion control systems.

Overview

The SIMOTICS S-1FK2 family of motors is known for its compact design, high power density, and ability to handle overload situations. These features make it a versatile choice for diverse industrial environments. The motor’s combination of low inertia and precise control allows for excellent performance in both highly dynamic and stable medium-inertia applications.

The extended 1FT2 series builds on the 1FK2 platform by offering finer gradation in speed ranges, additional torque options, and more configuration choices. This flexibility ensures that industries with specialized or demanding drive requirements can find an optimized solution within the SIMOTICS portfolio.

Product Code: 1FK2105-6AF10-1SA0
