1FK2204-5AF00-0MB0 SIEMENS Exclusive SIMOTICS S-1FK2 CT Servo Motor Original Brand New

1FK2204-5AF00-0MB0 SIEMENS Exclusive SIMOTICS S-1FK2 CT Servo Motor Original Brand New

The SIEMENS 1FK2204-5AF00-0MB0 SIMOTICS S-1FK2 CT servo motor is a compact and high-dynamic synchronous motor engineered for a wide range of industrial automation applications. Designed with precision and performance in mind, this servo motor delivers a rated torque of 2.4 Nm and a rated power of 0.75 kW at 3000 rpm (380-480 V) and 0.375 kW at 1500 rpm (200-240 V). Its IP64 degree of protection ensures reliable operation in challenging industrial environments while its cylindrical shaft (D19x40mm) allows versatile mechanical integration.

Equipped with a 22-bit single-turn and 12-bit multi-turn absolute encoder (AM22DQC) and DRIVE-CLiQ M17 plug, this SIMOTICS S-1FK2 motor provides precise feedback for advanced motion control. The M17 power connector ensures stable and secure electrical connections. The motor series emphasizes high power density, exceptional overload capability, and low inertia, enabling highly dynamic responses for applications with both low and medium moving masses.

Overview

The SIMOTICS S‑1FK2 servo motors are designed to address the essential challenges in servo drive technology. They form the core of the SINAMICS S210 drive system, offering a limited but carefully selected range of variants for easier selection and integration. The series also features high dynamic motors for rapid response applications and compact motors for stable and precise control of medium to high masses. With fine engineering, the motors achieve precise positioning and smooth operation across a wide variety of industrial processes.

The SIMOTICS S‑1FK2 portfolio extends to the 1FT2 motors, which offer additional torque levels, rated speed options, and diverse variations to meet more demanding requirements. This flexibility ensures that both standard and specialized industrial applications can be handled efficiently, providing users with a reliable and long-lasting servo solution. The combination of high dynamic response, compact design, and absolute encoder technology makes the 1FK2204-5AF00-0MB0 motor ideal for precise automation tasks, robotics, conveyor systems, and other servo-driven machinery.

Download

Data Sheet (PDF)

Product Code: 1FK2204-5AF00-0MB0
