1FK2204-5AK10-1SA0 SIEMENS Exclusive SIMOTICS S-1FK2 CT Servo Motor Original Brand New
$714.69
The SIEMENS 1FK2204-5AK10-1SA0 SIMOTICS S-1FK2 CT servo motor delivers high dynamic performance, precise control, and compact design with absolute encoder and holding brake for advanced industrial applications.
1FK2204-5AK10-1SA0 SIEMENS Exclusive SIMOTICS S-1FK2 CT Servo Motor Original Brand New
The SIEMENS SIMOTICS S-1FK2 CT servo motor with product code 1FK2204-5AK10-1SA0 is an exclusive high-performance motor engineered for demanding industrial applications. With a rated torque of 2.4 Nm and power outputs of 0.57 kW at 6000 rpm (380-480 V) and 0.75 kW at 3000 rpm (200-240 V), this motor combines precision, efficiency, and dynamic performance. It comes equipped with a holding brake, a robust D19x40 mm shaft with feather key, and a high-resolution absolute encoder (22-bit, AS22DQC) with OCC interface, providing accurate positioning and repeatability.
The compact design and IP64 degree of protection make the 1FK2 servo motor ideal for installation in a variety of industrial environments. Its rotatable M17 plug allows flexible electrical connection, simplifying integration into existing systems. This motor excels in applications requiring rapid acceleration, precise motion control, and minimal energy loss, making it a perfect companion for SINAMICS S210 servo drive systems.
Overview
The SIMOTICS S‑1FK2 series is designed for high dynamic response and precise control, even under varying load conditions. These motors are highly compact, ensuring stable operation with medium to high inertia loads. They offer excellent overload capability and high power density, allowing engineers to achieve optimal performance in confined spaces. The 1FK2 series forms the core of the servo drive system, delivering reliable and consistent operation in industrial automation.
For more demanding applications or environments, the 1FT2 series extends the capabilities of 1FK2 motors, offering finer speed gradations, additional torque levels, and numerous configuration options. This flexibility ensures that both standard and highly specialized drive requirements can be met efficiently. The high dynamic response of the SIMOTICS S‑1FK2 ensures that even low-mass components can be controlled with precision and speed.
Download
Product Code: 1FK2204-5AK10-1SA0
More Siemens products at Turll.com
| Weight | 3.75 kg |
|---|---|
| Dimensions | 452 × 250 × 267 mm |
