1FK7022-5AK71-1LH5-ZJ32 SIEMENS Exclusive SIMOTICS S-1FK7 Compact Servo Motor Original Brand New

1FK7022-5AK71-1LH5-ZJ32 SIEMENS Exclusive SIMOTICS S-1FK7 Compact Servo Motor Original Brand New

The SIEMENS 1FK7022-5AK71-1LH5-ZJ32 is part of the SIMOTICS S-1FK7 servo motor family, designed to deliver reliable performance in a wide range of industrial automation applications. With a torque of 0.85 Nm, a rated speed of 6000 rpm, and a power rating of 0.38 kW, this compact synchronous motor combines efficiency with adaptability. It features a naturally cooled design, a plain shaft with holding brake, and absolute encoder technology with 20-bit resolution plus 12-bit multi-turn capability using a DRIVE-CLiQ interface. The motor is protected with IP65 housing (IP67 at the flange), ensuring long-lasting operation in demanding environments. Additionally, this unit includes the ALPHA SP+ SP 060S-MF2 planetary gearing, two stages with a ratio of 16, making it ideal for precision applications.

Developed for flexibility, the SIMOTICS S-1FK7 motor supports connector rotation up to 270°, allowing easy installation in restricted spaces. Its paint finish in RAL7016 further enhances durability. The product integrates seamlessly with SINAMICS S120 and S220 drive systems, enabling precise speed and position control. With high overload capacity, compact construction, and stable closed-loop control, this motor delivers exceptional value in modern machine generations.

Overview

The SIMOTICS S-1FK7 family offers compact permanent-magnet synchronous motors engineered for universal applications. A wide range of encoders and gearbox options makes it possible to tailor the motor to specific needs. With their modular design and robust construction, these motors are suitable for industries requiring space-saving installations and high performance. They dissipate heat naturally through the motor surface, eliminating the need for external cooling, and provide excellent overload capability for continuous operation.

Benefits

• Space-saving compact design with high power density.
• Universal motor range adaptable to multiple industries.
• Low rotor inertia ensures extremely dynamic response in high-speed applications.
• Stable closed-loop performance under varying load conditions.
• Reduced commissioning time due to minimal optimization requirements.

Applications

• Machine tools and industrial robots.
• Handling systems and auxiliary axes.
• Wood, glass, ceramics, and stone processing equipment.
• Packaging, plastics, and textile machinery.
• Printing systems and other high-precision equipment.

Product Code: 1FK7022-5AK71-1LH5-ZJ32
