1FK7032-2AF21-1CH0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$1,917.18
The SIEMENS 1FK7032-2AF21-1CH0 SIMOTICS S synchronous motor delivers 0.31 kW power, 1.2 Nm torque, 3000 rpm speed, and IP64 protection, making it ideal for machine tools, automation, and robotics.
1FK7032-2AF21-1CH0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS 1FK7032-2AF21-1CH0 is a premium synchronous motor from the renowned SIMOTICS S series, built to deliver reliability, precision, and flexibility across a wide range of industrial environments. This compact unit combines a rated power of 0.31 kW with a torque of 1.2 Nm at 3000 rpm, offering stable performance even under demanding operational conditions. Designed for naturally cooled operation, the motor ensures efficient energy transfer without requiring external cooling systems, making it ideal for long-term use in diverse applications.
The 1FK7032-2AF21-1CH0 features an absolute encoder system with 24-bit resolution plus a 12-bit multi-turn interface, providing accurate feedback for speed and position control. Equipped with a smooth shaft, integrated holding brake, and IP64 protection rating, this model is engineered to withstand challenging industrial conditions. Its DRIVE-CLiQ interface ensures seamless integration with SIEMENS SINAMICS drive systems, resulting in improved productivity, simplified commissioning, and high system reliability.
Overview
SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors that combine advanced design with versatility. Available in multiple variants with different encoders and mechanical options, these motors can be tailored to match modern machine requirements. When paired with SINAMICS S120 or S220 drive systems, they create a highly dynamic solution with exceptional control characteristics.
Benefits
- Space-saving installation thanks to high power density
- Flexible options for universal use across industries
- High overload capability for demanding workloads
- Accurate speed and position control with integrated encoder systems
- Variants designed for compact, high dynamic, or high inertia applications
Application
- Machine tools and industrial robots
- Handling systems and automation equipment
- Wood, glass, ceramic, and stone processing machinery
- Packaging, plastic, and textile machines
- Printing systems and auxiliary axes
Download
Product Code: 1FK7032-2AF21-1CH0
More Siemens products at Turll.com
| Weight | 3 kg |
|---|
