1FK7032-2AF21-1QA2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7032-2AF21-1QA2 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7032-2AF21-1QA2 is an advanced SIMOTICS S synchronous motor, engineered to deliver precision, reliability, and flexibility for a wide variety of automation tasks. With a rated power of 0.31 kW, torque of 1.2 Nm at 3000 rpm, and a naturally cooled design, this exclusive motor is ideal for applications requiring consistent performance in compact environments. Built with a rotatable power connector and a flange mounting system (IMB 5 / IM V1 / IM V3), the motor ensures easy installation and adaptability to different machine setups. Its single-turn absolute encoder with 20-bit resolution and DRIVE-CLiQ interface enables precise feedback for position and speed control.

One of the key strengths of the SIMOTICS S-1FK7 motor family is its modular approach. The 1FK7032-2AF21-1QA2 can be perfectly integrated with SIEMENS SINAMICS S120 or S220 drive systems to create a highly functional and efficient drive solution. The compact structure, combined with high overload capacity, makes it suitable for demanding machine generations that need both flexibility and endurance. The motor’s robust protection level of IP65 (with DE flange rated at IP67) enhances durability in industrial environments where dust and moisture resistance are essential.

Overview

• Compact permanent-magnet synchronous motor with high power density
• Available with a wide selection of encoders and gearboxes for different applications
• Designed for natural cooling with efficient heat dissipation through the housing
• High overload capacity for stable and reliable operation

Benefits

• Space-saving installation thanks to compact dimensions
• Excellent dynamic performance with low rotor inertia
• Robust closed-loop control for varying load conditions
• Reduced commissioning effort due to optimized design

Application

• Machine tools, packaging, and printing machines
• Robotics and handling systems
• Wood, glass, ceramics, and textile industries
• Auxiliary axes for automation systems

Download

Data Sheet (PDF)

Product Code: 1FK7032-2AF21-1QA2
