The SIEMENS 1FK7032-2AF21-1RG1-ZJ15 SIMOTICS S synchronous motor offers precise performance with 0.31 kW output, 1.2 Nm torque, 3000 rpm speed, advanced encoder, and integrated planetary gearing for high-precision applications.
The SIEMENS 1FK7032-2AF21-1RG1-ZJ15 is an advanced SIMOTICS S synchronous motor engineered to deliver high efficiency and reliable performance for a wide range of automation requirements. With a rated power output of 0.31 kW, torque of 1.2 Nm, and a speed rating of 3000 rpm, this compact motor provides robust performance in a naturally cooled design. Its IMB 5 (IM V1, IM V3) flange mounting and rotatable power connector make integration both flexible and convenient.
Equipped with an absolute multi-turn encoder AM20DQI, featuring 20-bit resolution plus 12-bit multi-turn capability via DRIVE-CLiQ interface, the motor ensures precise control in demanding industrial processes. Built with a smooth shaft and IP65 degree of protection, it offers durability and long service life even in challenging environments.
One of the highlights of this configuration is the inclusion of the ALPHA SP+ planetary gearing, type SP 075S-MF2, with a two-stage reduction ratio of 28. This gearing system, complete with feather key design, enhances torque transmission and allows the motor to be used in applications where high precision and compact installation are essential. The combination of robust mechanics, advanced encoder technology, and gear integration results in superior adaptability across industries.
The SIMOTICS S-1FK7 series represents a versatile family of compact permanent-magnet synchronous motors. These motors are widely recognized for their ability to meet the continuously growing demands of modern machine generations. With various options for encoders, gearboxes, and configurations, the 1FK7 series can be customized to fit specific industrial tasks. By pairing seamlessly with SINAMICS S120 or S220 drive systems, they create a powerful automation solution with high dynamic performance and precise control. Thanks to surface cooling and an impressive overload capability, the motors ensure operational stability and efficiency in different environments.
Product Code: 1FK7032-2AF21-1RG1-ZJ15
More Siemens products at Turll.com
| SKU / Model | 1FK7032-2AF21-1RG1-ZJ15 |
|---|---|
| Weight | 6.601 kg |
