1FK7032-2AK71-1CG1-ZJ13 SIEMENS Exclusive SIMOTICS S Synchronous Motor with Planetary Gear Original Brand New

1FK7032-2AK71-1CG1-ZJ13 SIEMENS Exclusive SIMOTICS S Synchronous Motor with Planetary Gear Original Brand New

The SIEMENS 1FK7032-2AK71-1CG1-ZJ13 is an advanced synchronous motor from the SIMOTICS S-1FK7 series, designed to meet the evolving requirements of modern industrial automation. With a rated power of 0.5 kW, torque of 1.15 Nm at 6000 rpm, and compact IMB 5 flange design, this model delivers reliable performance in a space-saving form factor. It comes naturally cooled with IP65 protection, ensuring durability in challenging environments. The integrated absolute encoder (AM24DQI) with DRIVE-CLiQ interface provides high-resolution feedback, making it ideal for precise speed and position control.

This motor variant includes the J13 planetary gearing option, featuring the ALPHA SP+ SP 060S-MF2 two-stage gear with a ratio of 20:1 and feather key connection. The integration of gearbox technology enhances torque transmission while maintaining smooth, efficient operation. Combined with SINAMICS S120 or S220 drive systems, the 1FK7032-2AK71-1CG1-ZJ13 forms a high-performance drive package with exceptional flexibility and robust control.

Overview

SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors with a wide selection of encoder systems, gear combinations, and design options. Their flexibility makes them suitable for a variety of applications, from high-speed positioning to demanding production tasks. Built for operation without external cooling, heat is dissipated through the motor housing, supporting high overload capacity and dependable performance in continuous duty.

Benefits

• Compact size with high power density, enabling space-efficient installations
• Wide product range adaptable to various automation requirements
• High dynamic response through low rotor inertia
• Robust closed-loop control, suitable for variable load conditions
• Minimal setup and commissioning time with optimized control systems

Applications

• Machine tools and robotics
• Packaging, plastics, and textile machinery
• Wood, glass, ceramics, and stone processing
• Printing equipment and auxiliary axes

Download

Data Sheet (PDF)

Product Code: 1FK7032-2AK71-1CG1-ZJ13
