1FK7032-2AK71-1CG1-ZJ15 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7032-2AK71-1CG1-ZJ15 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7032-2AK71-1CG1-ZJ15 is part of the high-performance SIMOTICS S-1FK7 family of synchronous motors, designed for precision, efficiency, and reliability in industrial automation. With a compact construction and robust engineering, this exclusive model delivers rated power of 0.5 kW, a rated torque of 1.15 Nm, and a nominal speed of 6000 rpm. It operates with a 600V DC supply and features a naturally cooled IMB 5 design. The smooth shaft, encoder system AM24DQI with DRIVE-CLiQ interface, and rotatable power connector make it versatile for demanding applications where accuracy and dynamic performance are critical.

This motor is engineered to integrate seamlessly with SINAMICS S120/S220 drive systems, forming a complete automation solution that ensures precise motion control. The integrated multi-turn encoder supports detailed position feedback, enhancing efficiency in motion-driven operations. Without a holding brake but equipped with IP65 protection, the device is resilient against dust and water, making it reliable in challenging environments. The inclusion of a high-quality planetary gearbox (ALPHA SP+ 075S-MF2, two stages, ratio 28, with feather key) adds extra versatility, enabling smooth torque transmission with minimal losses.

Overview

SIMOTICS S-1FK7 motors are compact permanent-magnet synchronous motors with outstanding adaptability. Available in multiple variants, they are designed for machine generations that demand consistent reliability and higher efficiency. The series offers compatibility with various encoders and gear units, ensuring flexibility across applications while maintaining energy efficiency and reduced commissioning time.

Benefits

• Compact installation enabled by high power density
• Universal suitability for a wide variety of industrial applications
• Dynamic variants for rapid response thanks to low rotor inertia
• High inertia options for applications with fluctuating load conditions
• Minimal effort for commissioning and optimization

Application

• Machine tools requiring precision and stability
• Robotics and handling systems with complex motion profiles
• Wood, glass, ceramics, and stone processing equipment
• Packaging, plastic, and textile production lines
• Printing machinery and auxiliary axis systems

Download

Data Sheet (PDF)

Product Code: 1FK7032-2AK71-1CG1-ZJ15
