1FK7032-2AK71-1CH1-ZJ09 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7032-2AK71-1CH1-ZJ09 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7032-2AK71-1CH1-ZJ09 is a premium synchronous motor designed for maximum performance and reliability in industrial automation. As part of the SIMOTICS S-1FK7 series, this motor combines compact construction with advanced features, making it an excellent solution for applications requiring precision, durability, and energy efficiency. With a rated power of 0.5 kW, a nominal speed of 6000 rpm, and natural cooling, it ensures dependable operation in demanding environments. The integrated AM24DQI encoder with DRIVE-CLiQ interface provides absolute position feedback, enabling accurate control and synchronization in complex systems. A robust holding brake further enhances operational safety, while the IP65 protection rating ensures resistance against dust and water ingress.

Overview

The SIMOTICS S-1FK7 family is built around permanent-magnet synchronous technology, known for its high torque density and compact footprint. This makes the motors ideal where space is limited but performance cannot be compromised. The modular system allows for flexibility with different encoder options and gear combinations. Thanks to its planetary gearing ALPHA SP+ SP 060S-MF1, configured in a single stage with an I=10 ratio, this version delivers smooth mechanical power transmission while minimizing energy losses.

Benefits

• Space-saving installation due to high power density and compact design
• Versatility for use in machine tools, robotics, packaging systems, and more
• Enhanced precision with absolute multi-turn encoder technology
• Low maintenance requirements with rugged mechanical construction
• High overload capacity for demanding duty cycles

Applications

• Machine tools and automation lines
• Robots and handling systems
• Wood, glass, ceramics, and stone processing
• Packaging, plastics, and textile machinery
• Printing machines and auxiliary axes

Download

Data Sheet (PDF)

Product Code: 1FK7032-2AK71-1CH1-ZJ09
