The SIEMENS 1FK7032-2AK71-1CH1-ZJ37X01 SIMOTICS S motor is an advanced synchronous solution designed to deliver precision, efficiency, and long-term reliability in demanding automation environments. With a rated power of 0.5 kW, a torque of 1.15 Nm at 100K, and a rated speed of 6000 rpm, this motor combines high performance with compact design. Featuring natural cooling, IMB 5 construction, and a rotatable flange power connector, the device is built to provide flexible installation options for a wide range of industrial applications.

This exclusive model is equipped with an absolute encoder AM24DQI (24-bit + 12-bit multi-turn) connected via DRIVE-CLiQ interface, ensuring superior accuracy in speed and position control. The smooth shaft design with holding brake offers stability and safety, while IP65 protection ensures resistance against dust and moisture, making the motor highly reliable even in harsh environments. In addition, the J37 Alpha SP+ planetary gearbox with a reduction ratio of 1:50 enhances torque transmission, making the motor suitable for demanding motion control tasks. The unit also features a dull black RAL9005 paint finish for added durability.

Overview

The SIMOTICS S-1FK7 family is known for compact permanent-magnet synchronous motors that combine high power density with flexibility. Various options, encoder types, and gearboxes allow these motors to adapt to different applications while meeting the ever-growing performance demands of modern machine generations. When paired with SINAMICS S120 or S220 drive systems, they form a powerful automation solution with precise control and broad functionality. With high overload capability and surface cooling design, these motors are engineered for durability and consistent output.

Benefits

• Compact installation with exceptional power density
• Available in multiple ranges for universal use
• High Dynamic versions offer rapid response with minimal inertia
• High Inertia models ensure robust closed-loop control for variable loads
• Minimal commissioning effort for disturbance compensation

Applications

• Machine tools and robotics
• Handling and automation systems
• Wood, glass, ceramics, and stone processing
• Packaging, plastics, and textile machinery
• Printing machines and auxiliary axes

Download

Data Sheet (PDF)

Product Code: 1FK7032-2AK71-1CH1-ZJ37X01
