1FK7032-2AK71-1FG0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

1FK7032-2AK71-1FG0 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New

The SIEMENS 1FK7032-2AK71-1FG0 SIMOTICS S synchronous motor is a highly reliable compact drive solution designed to meet the increasing demands of modern machinery. With a rated power of 0.5 kW, 1.15 Nm torque at 100K, and a speed of up to 6000 rpm, this motor delivers outstanding performance in a wide range of industrial applications. The unit features natural cooling, IMB5 mounting options (IM V1, IM V3), and a rotatable power connector that ensures flexible installation in different layouts. Built with an absolute encoder AM22DQ offering 22-bit + 12-bit multiturn resolution and a DRIVE-CLiQ interface, the motor provides precise control over speed and positioning. Its plain shaft with standard tolerance N and IP64 protection rating ensures durability even in demanding environments.

The SIMOTICS S-1FK7 motors are permanent-magnet synchronous motors that can be perfectly adapted to diverse industrial needs through various encoders and gearboxes. When combined with SINAMICS S120 or S220 drive systems, they create a robust and efficient motion control solution. Their integrated encoder technology guarantees precise performance while maintaining high overload capacity, making them a trusted choice for critical automation processes. Designed for surface cooling, the motor efficiently dissipates heat, reducing maintenance and maximizing reliability over long operating cycles.

Overview

• Compact synchronous motors with high power density
• Flexible adaptation using encoders and gearboxes
• Integration with SINAMICS drive systems
• Natural cooling design for efficient heat dissipation
• High overload capability and robust operation

Benefits

• Space-saving installation and universal applications
• High dynamic response for precise positioning
• Stable control properties under varying load conditions
• Reduced commissioning effort and system optimization

Applications

• Machine tools and robotics
• Wood, glass, ceramics, and stone processing
• Packaging, textile, and plastic machines
• Printing systems and auxiliary axes

Download

Data Sheet (PDF)

Product Code: 1FK7032-2AK71-1FG0
