1FK7032-2AK71-1QG0-ZV40 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
$2,046.39
The SIEMENS 1FK7032-2AK71-1QG0-ZV40 SIMOTICS S synchronous motor delivers 0.5 kW power, 1.15 Nm torque, 6000 rpm speed, planetary gearing, and absolute encoder for precision industrial motion systems.
1FK7032-2AK71-1QG0-ZV40 SIEMENS Exclusive SIMOTICS S Synchronous Motor Original Brand New
The SIEMENS 1FK7032-2AK71-1QG0-ZV40 is a premium SIMOTICS S synchronous motor engineered for high performance and precision. With a rated power of 0.5 kW, a torque of 1.15 Nm at 100K, and a nominal speed of 6000 rpm, this compact motor delivers outstanding efficiency in demanding applications. Designed for naturally cooled operation and built in IMB 5 format, the motor ensures reliable operation with minimal maintenance. The integrated absolute encoder AS20DQI with DRIVE-CLiQ interface enhances accuracy in speed and position control, making it an excellent choice for advanced motion systems.
Its smooth shaft with fitted key and planetary gearing (ALPHA LP+, LP 070-MO1, 1 stage, I = 5) provides robust torque transmission, while the IP64 degree of protection safeguards the motor against dust and splashes. The rotatable flange connector further simplifies installation, offering flexibility in various mounting scenarios. This exclusive SIEMENS synchronous motor is ideally suited for integration with SINAMICS S120 and S220 drive systems, forming a complete, high-functionality automation solution.
Overview
The SIMOTICS S-1FK7 motor series is known for its compact design, adaptability, and wide range of configurations. Options for encoders, gear units, and mechanical interfaces allow engineers to tailor each motor to specific requirements. The series is optimized for applications where space efficiency, precise control, and high power density are critical. With their overload capability and durable construction, these motors ensure dependable operation across diverse industries.
Benefits
- Space-efficient installation due to compact, high power density design
- Versatile configurations suitable for universal applications
- High dynamic response enabled by low rotor inertia
- Stable closed-loop control for variable load conditions
- Reduced commissioning time and reliable compensation of disturbances
Applications
- Machine tools and precision manufacturing
- Robotics and automated handling systems
- Wood, glass, ceramics, and stone processing equipment
- Packaging, plastics, and textile machines
- Printing systems and auxiliary industrial axes
Download
Product Code: 1FK7032-2AK71-1QG0-ZV40
More Siemens products at Turll.com
| Weight | 4.601 kg |
|---|
